Samsung DV448AEP - Drum Back Removal (Continued)

Disassembly and Reassembly _ 21
Part Figure Description
Drum Back Removal
(Continued)
1. DisconnectthePowerSupplytotheunit.
2. RemovethePanelControl,theMainPCB,theTop.
Cover,theFrameFront,theDrumFrontandthe
Drum.
3. Remove7screwsfromtheDrumBack.
4. Remove2screwsfromtheValve-Water.
5. SeparatethewireintheWireHolder.
6. SeparatetheDrumBackfromtheFrame.
