Samsung DV448AEP - Drum Front Removal (Continued)

14 _ Disassembly and Reassembly
Part Figure Description
Drum Front Removal
(Continued)
1. Disconnectthepowersupplytotheunit.
2. RemovethePanelControl,theMainPCB,the
CoverTopandtheFrameFront.
3. DisconnectInteriorLightwiringHarness.
4. RemovethefourBracketDrumFront5screws.
5. DisconnecttheMoistureSensorwiringHarness.
6.RemovetheDrumFront.
7. Removethelter.
8. Remove2screwsfromtheDuctOulet.
