Disassembly and Reassembly _ 15
Part Figure Description
Drum Front Removal
9. RemovetheDuctOutlet.
10.Remove2screwsfromtheCaseFilter(F).
11.Remove1screwfromtheCaseFilter(B).
MakesuretheFilterdoesnotgetdamagedby
theRoller.
12.RemovetheCaseFilter(B/F).
13.Disconnect2HousingSensor-Plate.
14.Remove2Sensor-Plate.
