Samsung DV448AEP - Heater Removal

Disassembly and Reassembly _ 17
Part Figure Description
Heater Removal
1. Disconnectthepowersupplytotheunit.
2. RemovethePanelControl,theMainPCB,the
CoverTop,theFrameFront,theDrumFrontand
theDrum.
3. Removal6HousingHeater-Terminals.
4. Remove1screwfromtheHeater.
5. SeparatetheHeaterfromtheDrum-back.
6. Remove4screwsfromtheThermostats.
 Donotapplyexcessiveforcetotheterminal.
