Samsung DV448AEP - DOOR REVERSAL (Continued)

24 _ Disassembly and Reassembly
Part Figure Description
DOOR REVERSAL
(Continued)
11.TurntheHolder-Glassupsidedownandremove
the8screws.
12.Remove2Support-HingesandtheHinge-Door.
13.Removethescrew,inserttheremovedscrewinto
thebottomhole,andthenfastenit.
14.AssembletheSupport-HingeandtheHingesthat
youremovedinStep12,asshownbythegure
below.
15.Fastenthe8screwsthatyouremovedinStep11.
16.Install2Guide-HolderGlassesontotheotherside.
17.AssembletheHolder-Glassbyslidingitsothatthe
upperhookiscaughtandfastenthe15screwsthat
you removed in Step 9.
