Samsung DV448AEP - Model code: DV5471 AEW;XAA

Exploded views and Parts list _ 63
MODEL CODE: DV5471AEP/XAA
Service Bom (SA:SERVICEAVAILABLE,SNA:SERVICENOTAVAILABLE)
Drawing
No.
Code No. Description Specication QTY Un SA/SNA
0 DC97-16738A ASSY PANEL CONTROL ORCA-DRYER,DV5471AEP/XAA,INOX 1 PC SNA
1 6002-001306 SCREW-TAPPING TH,+,-
,1,M4,L14,ZPC(WHT),SWRCH18A,-
2 PC SA
1 6002-001306 SCREW-TAPPING TH,+,-
,1,M4,L14,ZPC(WHT),SWRCH18A,-
2 PC SA
1 6002-001306 SCREW-TAPPING TH,+,-
,1,M4,L14,ZPC(WHT),SWRCH18A,-
4 PC SA
2 DC63-01359A COVER-PANEL DV5471AEP,ABS,T3.0,W643.4,METAL
SILVER,HH106
1 PC SA
3 DC92-00619B ASSYPCBSUB ORCADRYER,SUB(C)PBA,120V~220V
50/60HZ,MCU,N
1 PC SA
4 DC92-00621B ASSYPCBSUB ORCADRYER,SUB(S)PBA,120V~220V
50/60HZ,DSP,N
1 PC SA
5 DC97-16068B ASSY KNOB ENCODER EAGLE-PJT,SQUALL,NO-PEARL/NO-
SPRING
1 PC SA
5-1 DC64-01642D KNOB-ENCODER HELIOS-C,ABS,T2.0,NO
PEARL,SILVER,NOSPRING
1 PC SNA
5-2 DC64-02222A DECORATION-ENCODER WF350ANW/
XAA,ABS,T6.0,W67.6,NTR,SQUALL
1 PC SNA
5-3 DC64-02223A DECORATION-ENCODER(I) WF350ANW/
XAA,ABS,T2.0,W57.7,NTR,SQUALL
1 PC SNA
6 DC97-16752A ASSY S.PANEL CONTROL ORCA-DRYER,DV5471AEP/
XAA,INOX,ENG
1 PC SA
6-1 6044-001852 RING-CS ID4.8,OD5.0,T0.25,BLK,SK5 14 PC SA
6-2 DC64-02614A BUTTON-PUSH DV5471AEP,ABS,GRAY 1 PC SA
6-3 DC64-02615A BUTTON-PUSH(O) DV5471AEP,ABS,GRAY 1 PC SA
6-4 DC64-02712A PANEL-CONTROL WA5471ABP/
XAA,ABS,T4.0,W647.7,L173.0,INOX-
GRAY
1 PC SA
6-5 DC64-02730B INLAY-PANEL DV5471AEP/
XAA,PET,T0.188,BLACK,BEST1
1 PC SA
