72 _ Exploded views and Parts list
MODEL CODE: DV5471AEP/XAA
Service Bom (SA:SERVICEAVAILABLE,SNA:SERVICENOTAVAILABLE)
Drawing
No.
Code No. Description Specication QTY Un SA/SNA
2-4 DC97-07618A ASSY GASKET PAD MDE9700AYW,DRYER/DRUM-
WRAPPER,-,-,-,-
2 PC SNA
3 DC97-16759A ASSYDRUMBACK ORCA-DRYER,DV5471AEP/XAA 1 PC SNA
3-1 DC60-50145A NUT-HEX MSWR,M10 2 PC SA
3-2 DC60-60060A WASHER -,T2,-,ID12,OD24,-,YEL,- 4 PC SA
3-3 DC61-01238A BRACKET-DRUMBACK 27-DRYER,SBHG1-A,T0.8,-,-,-,SIDE/
SGCC(GI)
2 PC SA
3-4 DC61-02063A GUIDE-NOZZLE DV448AEG/
XAA,PP(T142),T2.5,W68,L18,-,PURPLE
DRYER STEAM
1 PC SA
3-5 DC61-02826A BRACKET-DRUMBACK(B) DV520AEP/XAA,GI,T0.8 1 PC SA
3-6 DC61-03130A BRACKET-DRUMBACK DV5471AEP,EGI-
SECC,T1.0,L299.0,NTR
1 PC SA
3-7 DC66-00411C DRUM-BACK DV331AEW,EGI-SECC,T0.6,GRAY 1 PC SA
3-8 DC97-07521A ASSYDUCTAIR MDE7800AYW,DRYER,-,-,ELECTRIC,- 1 PC SA
3-9 DC97-07523B ASSY ROLLER -,27-DRYER,DRYER/EPDM,-,-,- 2 PC SA
3-9-1 DC61-01228A HOLDER-SHAFT WINGS-DRYER,NYLON#6,-,-,-
,NTR,ROLLER
2 PC SA
3-10 DC97-14929B ASSY STEAM KIT ACEDRYER,DV419AEW 1 PC SA
3-10-1 DC62-30042A VALVE-WATER DV448,PA66,80.8*97.6*44.7,0.2~13,-
,MISTVALVE
1 PC SA
3-10-2 DC67-00331A HOSE-DRAWER DV448AEW,NYLON,ID4.3,OD6.35,-
,L590,WHT,-
0.597 M SNA
3-10-3 DC97-14928A ASSY ELBOW DV448AEG/XAA,C3771BE-F 1 PC SNA
3-10-4 DC97-15601A ASSY NOZZLE ACEDRYER,DV419AEW,-,-,-,- 1 PC SNA
4 DC61-03052A DIE-RACK DRY DV5471AEP,PP,GRAY 1 PC SA
