Samsung DV448AEP - Model code: DV5471 AEP;XAA

Exploded views and Parts list _ 85
MODEL CODE: DV5471AEP/XAA
Service Bom (SA:SERVICEAVAILABLE,SNA:SERVICENOTAVAILABLE)
Drawing
No.
Code No. Description Specication QTY Un SA/SNA
0 DC90-06576A ASSYMOTORDUCT ORCA-DRYER,DV5471AEP/XAA 1 PC SNA
1 6602-001655 BELT-TIMING GEAR -,RUBBER,T3*W8,-,L2337,BLK 1 PC SA
2 DC93-00101E ASSY MOTOR ORCA-DRYER,DV5471AEP/XAA 1 PC SA
2-1 6021-001201 NUT-INCH LEFTTURN,3/8"-
24,ZPC(YEL),MSWR10,INCH
1 PC SA
2-2 DC31-00055D MOTORINDUCTION-
DRYER
dryermotor,DFS270ZSEL,4,110V-
120V,60Hz,5,1/3HP,B,1625,27"DRYER
1 PC SA
2-3 DC32-00007A THERMISTOR N3S1-K41-S1,10K,10KOHM 25,-40~105,-,5,-
,5,N3S1-K41-S1
1 PC SA
2-4 DC47-00016A THERMOSTAT PW-3V,AC125/250V,25A,85±5,-
35,25A,16,100Mohm,SAFETY
1 PC SA
2-5 DC61-01214A SPRING-PLATE WINGS-DRYER,SK-5,-,-,-,-,-,-,-,-,MOTOR 2 PC SA
2-6 DC67-00180A FAN WINGS-DRYER,FRPP(15%),-,-,-,MOTOR 1 PC SA
2-7 DC93-00098B ASSYCOVERDUCT GRACE-DRYER,DV520,GI/TB53 1 PC SA
2-7-1 DC61-02348A GUIDE-DUCTFAN 27-DRYER,GI,T0.6,-,-,-,- 1 PC SNA
2-7-2 DC61-02641A GUIDE-FAN 27-DRYER,PP,T2.0,W102.5,NTR,TB53 1 PC SNA
2-7-3 DC63-01026A COVER-DUCTFAN 27-DRYER,GI,T0.6,-,-,-,-,-,- 1 PC SNA
2-8 DC93-00282A ASSYDUCTCONNECTOR ORCA-DRYER,DV5471AEP 1 PC SA
2-8-1 DC67-00586A DUCT-CONNECTOR DV5471AEP,PP,T2.5,NTR 1 PC SNA
2-8-2 DC72-00032E ABSORBER SPONGE MDE9700AYW,EPDM,T3,W15,L740,BLK,C
OVER-FAN
1 PC SNA
2-9 DC96-00790C ASSY BRACKET MOTOR MDE9700AYW,DRYER,-,-,-,- 1 PC SNA
2-9-1 3405-001077 SWITCH-MICRO 125V,15A,180gf,2 1 PC SA
2-9-2 6002-000488 SCREW-TAPPING PH,+,NO,2S,M3,L16,ZPC(WHT),SWRCH1
8A
1 PC SA
2-9-3 6009-001342 SCREW-SPECIAL TH,+,-,M5,L11,ZPC(WHT),SWRCH18A,MAC
HINE,2BODY
1 PC SNA
2-9-4 DC61-01213A BRACKET-MOTOR WINGS-DRYER,HGI,T2.0,-,-,-,- 1 PC SA
2-9-5 DC61-01215B SPRING ETC-TENSION MDE9700AYW,HSWR,D1.8,-,D15,-
,22TURNS,-,ZPC2,-,-
1 PC SA
2-9-6 DC63-00919A COVER-SWITCH DV448,ABS+PC,T1.5,W13.7,L52,UL94-
V0,NATURAL
1 PC SA
2-9-7 DC96-00882C ASSY BRACKET IDLER MDE9700AYW,DRYER,-,-,-,- 1 PC SA
2-9-7-1 DC61-01228A HOLDER-SHAFT WINGS-DRYER,NYLON#6,-,-,-
,NTR,ROLLER
1 PC SA
2-9-7-2 DC61-01230B BRACKET-IDLER MDE9700AYW,HGI,T2.0,-,-,-,- 1 PC SA
2-9-7-3 DC66-00401A SHAFT-IDLER WINGS-DRYER,STS-410,-,-,-,-,FORMER 1 PC SNA
2-9-7-4 DC97-07509B ASSY ROLLER -,MDE9700AYW,DRYER/MOTOR/IDLER,-,-,- 1 PC SA
2-9-7-4-1 DC66-00402A ROLLER-IDLER WINGS-DRYER,POM,-,-,-,-,MOTOR 1 PC SA
