Exploded views and Parts list _ 95
MODEL CODE: DV5451AEW/XAA
Service Bom (SA:SERVICEAVAILABLE,SNA:SERVICENOTAVAILABLE)
Drawing
No.
Code No. Description Specication QTY Un SA/SNA
0 ASSYDUCTHEATER&DIE ORCA-DRYER 1
1 DC97-14486A ASSYDUCTHEATER 27-DRYER,-,-,-,ELECTRIC,- 1 PC SA
1-1 6002-000239 SCREW-TAPPING TH,+,NO,2S,M4,L8,ZPC(WHT),SWRC
H18A
2 PC SA
1-1 6002-000239 SCREW-TAPPING TH,+,NO,2S,M4,L8,ZPC(WHT),SWRC
H18A
7 PC SA
1-1 6002-000239 SCREW-TAPPING TH,+,NO,2S,M4,L8,ZPC(WHT),SWRC
H18A
2 PC SA
1-2 6002-001306 SCREW-TAPPING TH,+,-
,1,M4,L14,ZPC(WHT),SWRCH18A,-
1 PC SA
1-3 DC47-00018A THERMOSTAT 60T11,-,250V,25A,-20~150,-
30~150,25A,23.6,100M,-,260F-50F(HI-
LIMIT)
1 PC SA
1-4 DC47-00019A HEATER-DRY -,GD-PJT,-,5300W,21A,240,10,D1.3,-
,240V5300
1 PC SA
1-5 DC65-00013A TERMINAL-BLOCK GR-PJT,SERAMIC,2HOLE,1015
AWG#12,16*76,WHT,HEATER
1 PC SNA
1-6 DC67-00132A DUCT-HEATER(U) WINGS-DRYER,AL-COAT,T0.5,-,-
,NTR,UPPER
1 PC SNA
1-7 DC67-00133A DUCT-HEATER(L) WINGS-DRYER,AL-COAT,T0.5,-,-,NTR,- 1 PC SNA
1-8 DC96-00887A ASSY BRACKET
THERMOSTAT
MDE9700AYW,DRYER/ELECTRIC,-,- 1 PC SA
1-8-1 DC47-00015A THERMOSTAT PW-3V,250V,25A,160±5,-
35,25A,16,100M,SAFETY
1 PC SA
1-8-2 DC61-01204A BRACKET-THERMOSTAT WINGS-DRYER,SGCC(GI),T0.6,-,-,-,- 1 PC SA
2 DC61-02016A DIE-HEATER DV438AEW/XAA,SECC(EGI),-,-
,NTR,T1.2
1 PC SA
