Samsung DV448AEP - Model code: DV5471 AGP;XAA

Exploded views and Parts list _ 97
MODEL CODE: DV5471AGP/XAA
Service Bom (SA:SERVICEAVAILABLE,SNA:SERVICENOTAVAILABLE)
Drawing
No.
Code No. Description Specication QTY Un SA/SNA
0 ASSYDUCT&BURNER ORCA-DRYER 1
1 DC97-10720A ASSYDUCT MDG9700AWW,-,-,-,GAS,- 1 PC SA
1-1 6002-000231 SCREW-TAPPING TH,+,NO,2S,M4,L12,ZPC(WHT),SWRC
H18A
1 PC SNA
1-1 6002-000231 SCREW-TAPPING TH,+,NO,2S,M4,L12,ZPC(WHT),SWRC
H18A
2 PC SNA
1-2 DC32-00008A SENSOR-RADIANT 10RS,GD-PJT,0~150,120,4.5,100,-,-
,FRAME GAS
1 PC SA
1-3 DC47-00017A THERMOSTAT 60T21,-,250V,15A/25A,-20~150,-
30~150,25A,23.6,100M,-,230F-50F(HI-
LIMIT)
1 PC SA
1-4 DC97-07602B ASSYDUCTCONE MDG9700AWW,ENTRY,-,-,GAS,- 1 PC SA
1-4-1 6002-000231 SCREW-TAPPING TH,+,NO,2S,M4,L12,ZPC(WHT),SWRC
H18A
3 PC SNA
1-4-2 DC67-00136B DUCT-CONE(F) WINGS-DRYER,AL-COAT,T0.6,-,-
,NTR,FRONT
1 PC SA
1-4-3 DC67-00137B DUCT-CONE(B) WINGS-DRYER,AL-COAT,T0.6,-,-
,NTR,BACK
1 PC SA
2 DC97-14492A ASSYBURNER -,-,-,- 1 PC SA
2-1 6006-001174 SCREW-TAPPING TH,+,WE,2S,M4,L12,ZPC(WHT),SWR
CH18A
3 PC SNA
2-2 6009-001476 SCREW-HEX HEX,+,M5,L10,ZPC(WHT),SWRCH18A,2 1 PC SA
2-3 DC61-01232A BRACKET-BURNER WINGS-DRYER,SECC(EGI),T1.0,-,-,-,- 1 PC SA
2-4 DC62-00200A TUBE-BURNER WINGS-DRYER,PRESS(GASUNIT),-,-,-
,-,MAYTAG G/S
1 PC SA
2-5 DC62-00201A VALVE-GAS GD-PJT,3WAY,MAX
10BAR,NTR,120V/50/60Hz/INCH
1 PC SA
2-6 DC99-00507A ASSY PIPE MDG9700AWW,-,GAS DRYER/ELBOW
ASSY,-,-,-
1 PC SA
3 DC61-01224A DIE-HEATER 27-DRYER,SECC(EGI),-,-,NTR,T1.2 1 PC SA
4 DC47-00022A HEATER-IGNITER 101D,MDG9700AWW,CERAMIC,120V,M
AX4.25A,120V,40~400,15,90,NORTON
1 PC SA
5 DC63-00623A ABSORBER-IGNITOR MDE9700AYW,FELT,T2,W10,L10,-
,IGNITOR
1 PC SA
6 DC97-09193A ASSY SCREW -,MDG9700AWW,-,-,NUT-
CIRCULAR+SCREW,-
1 PC SA
7 DC61-02642A BRACKET-IGNITER DV220AEW,GI-SGCC,T1.2,L12.8,NTR 1 PC SNA
