21
SAMSUNG strives to improve its products at all times. Both the design specifications and these user
instructions are thus subject to change without notice.
RADIO
LW
Usable sensitivity 60 dB
AM (MW)
Signal/noise ratio 40 dB
Usable sensitivity 54 dB
Total harmonic distortion 2 %
FM
Signal/noise ratio 62 dB
Usable sensitivity 5 dB
Total harmonic distortion 1.0 %
COMPACT DISC PLAYER
Frequency range 20 Hz - 20 KHz (± 1 dB)
Signal/noise ratio 90 dB (at 1 KHz) with filter
Distortion 0.05 % (at 1 KHz)
Channel separation 75 dB
Disc sizes Diameter: 120 or 80 mm. Thickness: 1.2 mm
AMPLIFIER
Output power
Main(6 Ω)
........................................
2 X 30 Watts RMS (total harmonic distortion : 10%)
Channel separation 50 dB
Signal/noise ratio 75 dB
GENERAL
Dimensions 350(W) x 60 (H) x 290(D) mm
Technical Specifications
