Samsung EV-1 - Speaker Connection; Connecting Your System to the Power Supply

GB
6
The main lead must be plugged into an appropriate socket.
Before plugging your system into a main socket, you must check the voltage.
1. Plug the main lead (marked AC Cord on the rear of the system) into an appropriate socket.
2. Press the On/Standby button to switch your ULTRA SLIM audio system on.
AM
FM
75
COAXIAL
ANTENNA
PHONES
SPEAKERS
(6 )
L
R
SPEAKERS
(6 )
L
R
—
+
—
+
(OPTICAL)
DIGITAL OUT
L
R
AUX IN
• Speaker Connection: Connect the Speaker cords(red/black) to the Speaker jack of the system.
(Right Speaker)
(Left Speaker)
Directions in Installing Speaker
• Installation in a place near heating apparatus, under directly of light or with high humidity may
cause performance deration of the speaker.
• Do not install on the wall or on a high place of pole or other unstable place to
prevent any safety accident caused by falling of the speaker.
• Do not take the speaker apart from TV or computer monitor.
The speaker near the TV or computer monitor may influence the quality of the screen display.
