iPOLiS Network Design Tool User Guide
Functions
19
 Status: Display the connecting status of each port.
 Port Speed: Decide transmission speed of each port. You have a choice of port speed:
1Mbps or 1Gbps.
 Hardware/Software NVR
A. Device Information: Basic information of an NVR object.
 Name: Specify the name of NVR.
 Location #1 ~ #4: Specify the location where the NVR is installed. According to a whole
system diagram, up to 4-depth location can be specified.
 Description: Input the relevant information on the NVR.
B. IP Configuration: Network information of an NVR object.
 Address Type: Specify one of network address type.
 IP Address: Enter network IP address.
 Subnet Mask: Enter subnet mask address.
 Gateway: Enter network gateway address.
 DNS Server: Enter DNS server address.
C. Device Capabilities: Performance of the NVR.
 Channel: Verify the maximum number of channels to be connected to the NVR.
 HDD Size (GB): Specify the recording capacity of the NVR.
 Recording Bit Rate: Specify the recording throughput of the NVR.
D. Channel Configuration: Specify camera/encoder to be connected each channel of NVR.
 Add Device: Resister selected devices for each channel.
Connectable Network Cameras/Encoders displays only the list of camera and
encoder which are physically connected to the NVR in your diagram.
 Apply to others: Apply profile setting to other selected camera.
 Name: Select a model name of device to be connected each channel.
 Ch > Video Setup: Specify one of profiles to be used in the NVR. When selecting a
profile, its profile video setting appears.
 Ch > Camera Setup: Specify profile setting of the camera.
