Preparations
Chapter 02
Ports
"
The colour and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve quality.
SERVICE 4
FANET
SERVICE 3
CAL
SERVICE 2
DEBUG
SWITCH
SERVICE 1
USB
DATA
DATA
100-240V
50/60Hz (Max 5.9A)
SERVICE 4
FANET
SERVICE 3
CAL
SERVICE 2
DEBUG
SWITCH
SERVICE 1
USB
DATA
DATA
100-240V
50/60Hz (Max 5.9A)
Parts Description
Dedicated to service technicians.
Connects to the port on the next cabinet.
Connects to the port on the next cabinet.
SWITCH
Enters factory mode (press and hold for 3 seconds) or factory reset
mode (press and hold for 10 seconds).
Connects to an AC power.
Connects the power cord to the next cabinet to support AC power.
