GB
6
Rear Panel View
1. CD Digital out Jack
2. FM Aerial Connector Terminal
3. AM(MW)/LW Aerial Connector Terminal
4. Aux-Input
5. Loudspeaker Connector Terminal
(IMPEDANCE 6Ω)
AM ANT
DIGITAL OUT
OPTICAL
FM ANT. (75Ω)
1
2
3
4
5
