DC25 2301-000375 “C-FILM,PEF;100nF,10%,TP,50V,11x12.5x6.5,”
DC26 2301-000375 “C-FILM,PEF;100nF,10%,TP,50V,11x12.5x6.5,”
FC15 2301-000375 “C-FILM,PEF;100nF,10%,TP,50V,11x12.5x6.5,”
FC13 2301-000375 “C-FILM,PEF;100nF,10%,TP,50V,11x12.5x6.5,”
DC7 2301-000375 “C-FILM,PEF;100nF,10%,TP,50V,11x12.5x6.5,”
KC12 2301-000379 “C-FILM,PEF;10nF,10%,50V,TP,6x12x3.5mm,-”
KC11 2301-000379 “C-FILM,PEF;10nF,10%,50V,TP,6x12x3.5mm,-”
DC24 2301-000379 “C-FILM,PEF;10nF,10%,50V,TP,6x12x3.5mm,-”
DC11 2301-000379 “C-FILM,PEF;10nF,10%,50V,TP,6x12x3.5mm,-”
DC16 2301-000404 “C-FILM,PEF;2.2nF,10%,50V,TP,5.5x12x3mm,-”
DC15 2301-000404 “C-FILM,PEF;2.2nF,10%,50V,TP,5.5x12x3mm,-”
DC14 2301-000404 “C-FILM,PEF;2.2nF,10%,50V,TP,5.5x12x3mm,-”
DC13 2301-000407 “C-FILM,PEF;2.7nF,10%,50V,TP,5.5x12x3mm,-”
WC9 2301-000412 “C-FILM,PEF;22nF,10%,50V,TP,8x12x4mm,-”
DC8 2301-000412 “C-FILM,PEF;22nF,10%,50V,TP,8x12x4mm,-”
DC31 2301-000412 “C-FILM,PEF;22nF,10%,50V,TP,8x12x4mm,-”
KC13 2301-000442 “C-FILM,PEF;4.7nF,10%,50V,TP,5.5x7x3mm,5m”
CC2 2301-000449 “C-FILM,PEF;47nF,10%,50V,TP,9.5x12.5x5mm,”
FC11 2301-000454 “C-FILM,PEF;5.6nF,10%,50V,TP,6x12x3,3.5mm”
FC12 2301-000454 “C-FILM,PEF;5.6nF,10%,50V,TP,6x12x3,3.5mm”
KC14 2301-000474 “C-FILM,PEF;8.2nF,10%,50V,TP,6.5x12x3.5,3”
RC6 2401-000357 “C-AL;100UF,0.2,50V,GP,8*12,5MM,SSL”
RC9 2401-000438 “C-AL;10uF,20%,25V,GP,-,5x11,5mm”
CC5 2401-000438 “C-AL;10uF,20%,25V,GP,-,5x11,5mm”
DC30 2401-000438 “C-AL;10uF,20%,25V,GP,-,5x11,5mm”
WC8 2401-000475 “C-AL;10uF,20%,50V,GP,TP,5x11mm,5mm”
WC3 2401-000475 “C-AL;10uF,20%,50V,GP,TP,5x11mm,5mm”
WC2 2401-000475 “C-AL;10uF,20%,50V,GP,TP,5x11mm,5mm”
DC2 2401-000778 “C-AL;220uF,20%,10V,GP,6.3x11,5MM,TP”
RC11 2401-000830 “C-AL;220uF,20%,25V,GP,TP,8x11.5,5”
RC10 2401-000907 “C-AL;22uF,20%,16V,GP,TP,5x11mm,5mm”
KC22 2401-000907 “C-AL;22uF,20%,16V,GP,TP,5x11mm,5mm”
FC10 2401-000907 “C-AL;22uF,20%,16V,GP,TP,5x11mm,5mm”
FC36 2401-001022 “C-AL;3.3UF,20%,50V,GP,TP,5X11,5”
FC35 2401-001022 “C-AL;3.3UF,20%,50V,GP,TP,5X11,5”
FC34 2401-001022 “C-AL;3.3UF,20%,50V,GP,TP,5X11,5”
FC1 2401-001022 “C-AL;3.3UF,20%,50V,GP,TP,5X11,5”
DC36 2401-001022 “C-AL;3.3UF,20%,50V,GP,TP,5X11,5”
DC35 2401-001022 “C-AL;3.3UF,20%,50V,GP,TP,5X11,5”
DC5 2401-001080 “C-AL;330nF,20%,50V,GP,-,5x11,2mm”
CCC1 2401-001102 “C-AL;330uF,20%,16V,GP,TP,8x11.5mm,5”
RC17 2401-001538 “C-AL;47uF,20%,25V,GP,TP,5x11mm,5mm”
RC8 2401-001625 “C-AL;6.8uF,20%,50V,GP,TP,5x11,5”
RC21 2401-001893 “C-AL;100uF,20%,16V,GP,6*7,5MM,TP”
RC20 2401-001893 “C-AL;100uF,20%,16V,GP,6*7,5MM,TP”
RC15 2401-001893 “C-AL;100uF,20%,16V,GP,6*7,5MM,TP”
KC23 2401-001893 “C-AL;100uF,20%,16V,GP,6*7,5MM,TP”
FC5 2401-001893 “C-AL;100uF,20%,16V,GP,6*7,5MM,TP”
FC31 2401-001912 “C-AL;1uF,20%,50V,GP,5*11,5mm,TP”
FC8 2401-001912 “C-AL;1uF,20%,50V,GP,5*11,5mm,TP”
FC9 2401-001912 “C-AL;1uF,20%,50V,GP,5*11,5mm,TP”
RC7 2401-001912 “C-AL;1uF,20%,50V,GP,5*11,5mm,TP”
DC20 2401-001912 “C-AL;1uF,20%,50V,GP,5*11,5mm,TP”
FC22 2401-001912 “C-AL;1uF,20%,50V,GP,5*11,5mm,TP”
FC23 2401-001912 “C-AL;1uF,20%,50V,GP,5*11,5mm,TP”
FC30 2401-001912 “C-AL;1uF,20%,50V,GP,5*11,5mm,TP”
RC13 2401-001954 “C-AL;4.7uF,20%,50V,GP,TP,5x11mm,5mm”
FC4 2401-001954 “C-AL;4.7uF,20%,50V,GP,TP,5x11mm,5mm”
FC33 2401-001954 “C-AL;4.7uF,20%,50V,GP,TP,5x11mm,5mm”
FC25 2401-001954 “C-AL;4.7uF,20%,50V,GP,TP,5x11mm,5mm”
FC2 2401-001954 “C-AL;4.7uF,20%,50V,GP,TP,5x11mm,5mm”
FC24 2401-001968 “C-AL;470nF,20%,50V,GP,TP,5x11mm,5mm”
DC32 2401-001975 “C-AL;47uF,20%,16V,GP,TP,5x11mm,5mm”
DC21 2401-001975 “C-AL;47uF,20%,16V,GP,TP,5x11mm,5mm”
DC12 2401-001975 “C-AL;47uF,20%,16V,GP,TP,5x11mm,5mm”
FC18 2401-002180 “C-AL;2.2uF,20%,50V,GP,TP,5x11mm,5mm”
FC19 2401-002180 “C-AL;2.2uF,20%,50V,GP,TP,5x11mm,5mm”
KC21 2401-002180 “C-AL;2.2uF,20%,50V,GP,TP,5x11mm,5mm”
KC6 2401-002180 “C-AL;2.2uF,20%,50V,GP,TP,5x11mm,5mm”
KC9 2401-002180 “C-AL;2.2uF,20%,50V,GP,TP,5x11mm,5mm”
DC9 2401-002180 “C-AL;2.2uF,20%,50V,GP,TP,5x11mm,5mm”
DC27 2401-002180 “C-AL;2.2uF,20%,50V,GP,TP,5x11mm,5mm”
DC28 2401-002180 “C-AL;2.2uF,20%,50V,GP,TP,5x11mm,5mm”
DC34 2401-002180 “C-AL;2.2uF,20%,50V,GP,TP,5x11mm,5mm”
DC6 2401-002180 “C-AL;2.2uF,20%,50V,GP,TP,5x11mm,5mm”
DC8 2401-002180 “C-AL;2.2uF,20%,50V,GP,TP,5x11mm,5mm”
CL2 2701-000116 “INDUCTOR-AXIAL;10uH,10%,4.2x9.8mm”
DL3 2701-000298 “INDUCTOR-AXIAL;470uH,10%,4.2x9.8mm”
RF1 3602-000147 “FUSE-CLIP;250V,7.5A,30mohm”
RF2 3602-000147 “FUSE-CLIP;250V,7.5A,30mohm”
PCB AH41-00434A “PCB;MAX-B550/570/VB555/D,-,-,-,-,3”
AH92-01387B “ASSY PCB-AMP;MAX-WB630,AMP ASSY,NO CE,23”
PIC1 1201-001582 “IC-POWER AMP;402-070,SIP,15P,-,DUAL,30dB”
PIC2 1201-001856 “IC-POWER AMP;STK442-090,SIP,14P,233MIL,S”
PR41 2003-000008 “R-METAL OXIDE(S);100ohm,5%,1W,AA,TP,3.3x”
PR42 2003-000008 “R-METAL OXIDE(S);100ohm,5%,1W,AA,TP,3.3x”
PR31 2003-000390 “R-METAL OXIDE(S);0.27OHM,5%,2W,AA,TP,”
PR32 2003-000390 “R-METAL OXIDE(S);0.27OHM,5%,2W,AA,TP,”
PR33 2003-000390 “R-METAL OXIDE(S);0.27OHM,5%,2W,AA,TP,”
PR34 2003-000390 “R-METAL OXIDE(S);0.27OHM,5%,2W,AA,TP,”
PR5 2003-000578 “R-METAL OXIDE(S);220ohm,5%,2W,AA,TP,4x12”
PR6 2003-000578 “R-METAL OXIDE(S);220ohm,5%,2W,AA,TP,4x12”
PR48 2009-001117 “R-METAL PLATE;0.1OHM,5%,5W,CL,BK,5X13X18”
PR58 2009-001117 “R-METAL PLATE;0.1OHM,5%,5W,CL,BK,5X13X18”
PR59 2009-001117 “R-METAL PLATE;0.1OHM,5%,5W,CL,BK,5X13X18”
PR47 2009-001117 “R-METAL PLATE;0.1OHM,5%,5W,CL,BK,5X13X18”
PR46 2009-001117 “R-METAL PLATE;0.1OHM,5%,5W,CL,BK,5X13X18”
PR45 2009-001117 “R-METAL PLATE;0.1OHM,5%,5W,CL,BK,5X13X18”
PC22 2401-000230 “C-AL;100uF,20%,100V,GP,TP,12.5x20mm”
PC23 2401-000230 “C-AL;100uF,20%,100V,GP,TP,12.5x20mm”
PC24 2401-000230 “C-AL;100uF,20%,100V,GP,TP,12.5x20mm”
PC25 2401-000230 “C-AL;100uF,20%,100V,GP,TP,12.5x20mm”
JVR1 3406-001054 “SWITCH-ROTARY;5V DC,0.5mA,-,7.5mm”
PREL1 3501-001197 “RELAY-MINIATURE;12VDC,0.54W,44.4mA,1Form”
PREL2 3501-001197 “RELAY-MINIATURE;12VDC,0.54W,44.4mA,1Form”
PW4 3708-000181 “CONNECTOR-FPC/FFC/PIC;16P,1.25mm,STRAIGH”
JCW1 3708-000451 “CONNECTOR-FPC/FFC/PIC;16P,1.25mm,STRAIGH”
PW1 3710-001793 “CONNECTOR-SOCKET;9P,1R,2.5MM,STRAIGHT,SN”
PW2 3710-001793 “CONNECTOR-SOCKET;9P,1R,2.5MM,STRAIGHT,SN”
PCW2 3711-004989 “CONNECTOR-HEADER;2WALL,9P,1R,2.5MM,ANGLE”
PCW1 3711-004989 “CONNECTOR-HEADER;2WALL,9P,1R,2.5MM,ANGLE”
SPJACK 3716-001164 “TERMINAL-BLOCK;SOLDER,8P,-,60V,7A”
6003-000276 “SCREW-TAPTITE;BH,+,B,M3,L10,ZPC(YEL),SWC”
6003-001230 “SCREW-TAPTITE;BH,+,B,M3,L16,ZPC(YEL),SWR”
PL5 AH27-90001A “COIL-SPRING;-,2.2UH,-,-,-,SPRING,-,-,-,-”
PL4 AH27-90001A “COIL-SPRING;-,2.2UH,-,-,-,SPRING,-,-,-,-”
PL3 AH27-90001A “COIL-SPRING;-,2.2UH,-,-,-,SPRING,-,-,-,-”
PL2 AH27-90001A “COIL-SPRING;-,2.2UH,-,-,-,SPRING,-,-,-,-”
PL1 AH27-90001A “COIL-SPRING;-,2.2UH,-,-,-,SPRING,-,-,-,-”
PL6 AH27-90001A “COIL-SPRING;-,2.2UH,-,-,-,SPRING,-,-,-,-”
PL7 AH27-90001A “COIL-SPRING;-,2.2UH,-,-,-,SPRING,-,-,-,-”
PL8 AH27-90001A “COIL-SPRING;-,2.2UH,-,-,-,SPRING,-,-,-,-”
PCW3 AH39-00295A “W/HARNESS UNIT;MAX-L85,-,-,9P,-,-,-,SCN-”
AH60-10051A “SCREW-TAPTITE;-,-,FE,-,B,M3,L8,-,-,-”
AH61-00973A “BRACKET-H/SINK,L;MAX-WB650,SECC T1.0,-,-”
AH61-00977A “BRACKET-H/SINK,R;NAX-WB650,SECC T1.0,-,-”
AH62-00063D “HEAT SINK-,M;MAX-B570,AL EXTR,-,-,-,-,-,”
PD5 0401-000101 “DIODE-SWITCHING;1N4148,100V,200mA,DO-35,”
PD4 0401-000101 “DIODE-SWITCHING;1N4148,100V,200mA,DO-35,”
PD3 0401-000101 “DIODE-SWITCHING;1N4148,100V,200mA,DO-35,”
PD1 0402-000127 “DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP”
PD2 0402-000127 “DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP”
PZD2 0403-000382 “DIODE-ZENER;UZP15B,15V,13.9-15.6V,1W,DO-”
PZD1 0403-000382 “DIODE-ZENER;UZP15B,15V,13.9-15.6V,1W,DO-”
PQ9 0501-000296 “TR-SMALL SIGNAL;KSA709-Y,PNP,800mW,TO-92”
PQ6 0501-000296 “TR-SMALL SIGNAL;KSA709-Y,PNP,800mW,TO-92”
PQ10 0501-000296 “TR-SMALL SIGNAL;KSA709-Y,PNP,800mW,TO-92”
PQ8 0501-000331 “TR-SMALL SIGNAL;KSC1009-Y,NPN,800mW,TO-9”
PQ5 0501-000331 “TR-SMALL SIGNAL;KSC1009-Y,NPN,800mW,TO-9”
PQ17 0501-000369 “TR-SMALL SIGNAL;KSC2331-Y,NPN,1000mW,TO-”
PQ16 0501-000369 “TR-SMALL SIGNAL;KSC2331-Y,NPN,1000mW,TO-”
PQ3 0501-000407 “TR-SMALL SIGNAL;KSD471A-Y,NPN,800mW,TO-9”
PQ4 0501-000407 “TR-SMALL SIGNAL;KSD471A-Y,NPN,800mW,TO-9”
PQ1 0501-000407 “TR-SMALL SIGNAL;KSD471A-Y,NPN,800mW,TO-9”
PQ11 0501-000407 “TR-SMALL SIGNAL;KSD471A-Y,NPN,800mW,TO-9”
PQ12 0501-000407 “TR-SMALL SIGNAL;KSD471A-Y,NPN,800mW,TO-9”
PQ14 0501-000407 “TR-SMALL SIGNAL;KSD471A-Y,NPN,800mW,TO-9”
PQ15 0501-000407 “TR-SMALL SIGNAL;KSD471A-Y,NPN,800mW,TO-9”
PQ2 0501-000407 “TR-SMALL SIGNAL;KSD471A-Y,NPN,800mW,TO-9”
PQ7 0504-001003 “TR-DIGITAL;KSR2003,PNP,300MW,22K/22K,TO-”
PQ13 0504-001003 “TR-DIGITAL;KSR2003,PNP,300MW,22K/22K,TO-”
JLD5 0601-001238 “LED;ROUND,RED,3.1mm,697nm”
JLD6 0601-001238 “LED;ROUND,RED,3.1mm,697nm”
JLD7 0601-001238 “LED;ROUND,RED,3.1mm,697nm”
JLD8 0601-001238 “LED;ROUND,RED,3.1mm,697nm”
JLD9 0601-001238 “LED;ROUND,RED,3.1mm,697nm”
JLD1 0601-001238 “LED;ROUND,RED,3.1mm,697nm”
JLD10 0601-001238 “LED;ROUND,RED,3.1mm,697nm”
JLD2 0601-001238 “LED;ROUND,RED,3.1mm,697nm”
JLD3 0601-001238 “LED;ROUND,RED,3.1mm,697nm”
JLD4 0601-001238 “LED;ROUND,RED,3.1mm,697nm”
PR69 2001-000008 “R-CARBON;15Kohm,5%,1/8W,AA,TP,1.8x3.2mm”
PR65 2001-000008 “R-CARBON;15Kohm,5%,1/8W,AA,TP,1.8x3.2mm”
PR66 2001-000010 “R-CARBON;68Kohm,5%,1/8W,AA,TP,1.8x3.2mm”
PR62 2001-000010 “R-CARBON;68Kohm,5%,1/8W,AA,TP,1.8x3.2mm”
JR18 2001-000221 “R-CARBON;1.2Kohm,5%,1/8W,AA,TP,1.8x3.2m”
PR36 2001-000241 “R-CARBON;1.5Kohm,5%,1/8W,AA,TP,1.8x3.2m”
PR28 2001-000241 “R-CARBON;1.5Kohm,5%,1/8W,AA,TP,1.8x3.2m”
JR22 2001-000241 “R-CARBON;1.5Kohm,5%,1/8W,AA,TP,1.8x3.2m”
JR1 2001-000258 “R-CARBON;1.8Kohm,5%,1/8W,AA,TP,1.8x3.2m”
PR56 2001-000273 “R-CARBON;100Kohm,5%,1/8W,AA,TP,1.8x3.2m”
PR57 2001-000273 “R-CARBON;100Kohm,5%,1/8W,AA,TP,1.8x3.2m”
PR70 2001-000273 “R-CARBON;100Kohm,5%,1/8W,AA,TP,1.8x3.2m”
PR72 2001-000273 “R-CARBON;100Kohm,5%,1/8W,AA,TP,1.8x3.2m”
PR4 2001-000273 “R-CARBON;100Kohm,5%,1/8W,AA,TP,1.8x3.2m”
PR20 2001-000273 “R-CARBON;100Kohm,5%,1/8W,AA,TP,1.8x3.2m”
PR13 2001-000273 “R-CARBON;100Kohm,5%,1/8W,AA,TP,1.8x3.2m”
PR1 2001-000273 “R-CARBON;100Kohm,5%,1/8W,AA,TP,1.8x3.2m”
PR79 2001-000290 “R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm”
PR78 2001-000290 “R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm”
PR76 2001-000290 “R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm”
PR30 2001-000290 “R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm”
JR7 2001-000290 “R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm”
PR64 2001-000302 “R-CARBON;10ohm,5%,1/8W,AA,TP,1.8x3.2mm”
PR68 2001-000302 “R-CARBON;10ohm,5%,1/8W,AA,TP,1.8x3.2mm”
Location no Code no. Description Specifiation Remarks Location no Code no. Description Specifiation Remarks
