JR20 2001-000405 “R-CARBON;180OHM,5%,1/8W,AA,TP,1.8X3.2MM”
JR21 2001-000405 “R-CARBON;180OHM,5%,1/8W,AA,TP,1.8X3.2MM”
JR4 2001-000405 “R-CARBON;180OHM,5%,1/8W,AA,TP,1.8X3.2MM”
JR5 2001-000405 “R-CARBON;180OHM,5%,1/8W,AA,TP,1.8X3.2MM”
JR6 2001-000405 “R-CARBON;180OHM,5%,1/8W,AA,TP,1.8X3.2MM”
JR11 2001-000405 “R-CARBON;180OHM,5%,1/8W,AA,TP,1.8X3.2MM”
JR12 2001-000405 “R-CARBON;180OHM,5%,1/8W,AA,TP,1.8X3.2MM”
JR13 2001-000405 “R-CARBON;180OHM,5%,1/8W,AA,TP,1.8X3.2MM”
JR14 2001-000405 “R-CARBON;180OHM,5%,1/8W,AA,TP,1.8X3.2MM”
JR15 2001-000405 “R-CARBON;180OHM,5%,1/8W,AA,TP,1.8X3.2MM”
PR51 2001-000429 “R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm”
PR81 2001-000429 “R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm”
PR82 2001-000429 “R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm”
PR84 2001-000429 “R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm”
PR85 2001-000429 “R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm”
PR50 2001-000429 “R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm”
JR19 2001-000429 “R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm”
PR15 2001-000429 “R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm”
PR18 2001-000429 “R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm”
PR19 2001-000429 “R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm”
PR24 2001-000429 “R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm”
JR2 2001-000449 “R-CARBON;2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m”
PR77 2001-000522 “R-CARBON;22Kohm,5%,1/8W,AA,TP,1.8x3.2mm”
PR74 2001-000522 “R-CARBON;22Kohm,5%,1/8W,AA,TP,1.8x3.2mm”
PR67 2001-000522 “R-CARBON;22Kohm,5%,1/8W,AA,TP,1.8x3.2mm”
PR63 2001-000522 “R-CARBON;22Kohm,5%,1/8W,AA,TP,1.8x3.2mm”
JR9 2001-000522 “R-CARBON;22Kohm,5%,1/8W,AA,TP,1.8x3.2mm”
JR3 2001-000591 “R-CARBON;3.3Kohm,5%,1/8W,AA,TP,1.8x3.2m”
PR53 2001-000660 “R-CARBON;33Kohm,5%,1/8W,AA,TP,1.8x3.2mm”
PR71 2001-000734 “R-CARBON;4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m”
PR73 2001-000734 “R-CARBON;4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m”
PR80 2001-000734 “R-CARBON;4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m”
PR83 2001-000734 “R-CARBON;4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m”
PR23 2001-000734 “R-CARBON;4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m”
JR50 2001-000734 “R-CARBON;4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m”
PR16 2001-000734 “R-CARBON;4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m”
PR17 2001-000734 “R-CARBON;4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m”
PR22 2001-000734 “R-CARBON;4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m”
PR61 2001-000780 “R-CARBON;470ohm,5%,1/8W,AA,TP,1.8x3.2mm”
PR60 2001-000780 “R-CARBON;470ohm,5%,1/8W,AA,TP,1.8x3.2mm”
PR21 2001-000780 “R-CARBON;470ohm,5%,1/8W,AA,TP,1.8x3.2mm”
PR14 2001-000780 “R-CARBON;470ohm,5%,1/8W,AA,TP,1.8x3.2mm”
PR75 2001-000786 “R-CARBON;47Kohm,5%,1/8W,AA,TP,1.8x3.2mm”
PR3 2001-000802 “R-CARBON;5.6Kohm,5%,1/8W,AA,TP,1.8x3.2m”
PR2 2001-000802 “R-CARBON;5.6Kohm,5%,1/8W,AA,TP,1.8x3.2m”
PR49 2001-000864 “R-CARBON;56Kohm,5%,1/8W,AA,TP,1.8x3.2mm”
PR52 2001-000864 “R-CARBON;56Kohm,5%,1/8W,AA,TP,1.8x3.2mm”
PR54 2001-000864 “R-CARBON;56Kohm,5%,1/8W,AA,TP,1.8x3.2mm”
PR55 2001-000864 “R-CARBON;56Kohm,5%,1/8W,AA,TP,1.8x3.2mm”
PR37 2001-000864 “R-CARBON;56Kohm,5%,1/8W,AA,TP,1.8x3.2mm”
JR10 2001-000864 “R-CARBON;56Kohm,5%,1/8W,AA,TP,1.8x3.2mm”
PR27 2001-000864 “R-CARBON;56Kohm,5%,1/8W,AA,TP,1.8x3.2mm”
PR29 2001-000864 “R-CARBON;56Kohm,5%,1/8W,AA,TP,1.8x3.2mm”
PR35 2001-000864 “R-CARBON;56Kohm,5%,1/8W,AA,TP,1.8x3.2mm”
JR8 2001-000890 “R-CARBON;6.8Kohm,5%,1/8W,AA,TP,1.8x3.2m”
JR17 2001-000995 “R-CARBON;820ohm,5%,1/8W,AA,TP,1.8x3.2mm”
PR12 2001-001000 “R-CARBON;82Kohm,5%,1/8W,AA,TP,1.8x3.2mm”
PR11 2001-001000 “R-CARBON;82Kohm,5%,1/8W,AA,TP,1.8x3.2mm”
PR40 2001-001077 “R-CARBON(S);150ohm,5%,1/2W,AA,TP,2.4x6.4”
PR39 2001-001077 “R-CARBON(S);150ohm,5%,1/2W,AA,TP,2.4x6.4”
PR25 2003-000008 “R-METAL OXIDE(S);100ohm,5%,1W,AA,TP,3.3x”
PR26 2003-000008 “R-METAL OXIDE(S);100ohm,5%,1W,AA,TP,3.3x”
PR44 2003-000428 “R-METAL OXIDE(S);1.5Kohm,5%,1W,AA,TP,3.3”
PR43 2003-000428 “R-METAL OXIDE(S);1.5Kohm,5%,1W,AA,TP,3.3”
PR9 2003-000689 “R-METAL OXIDE(S);4.7ohm,5%,1W,AA,TP,3.3x”
PR8 2003-000689 “R-METAL OXIDE(S);4.7ohm,5%,1W,AA,TP,3.3x”
PR7 2003-000689 “R-METAL OXIDE(S);4.7ohm,5%,1W,AA,TP,3.3x”
PR38 2003-000689 “R-METAL OXIDE(S);4.7ohm,5%,1W,AA,TP,3.3x”
PR10 2003-000689 “R-METAL OXIDE(S);4.7ohm,5%,1W,AA,TP,3.3x”
PC13 2201-000300 “C-CERAMIC,DISC;1nF,20%,50V,Y5T,TP,5x3,5”
PC12 2201-000300 “C-CERAMIC,DISC;1nF,20%,50V,Y5T,TP,5x3,5”
PC29 2201-000338 “C-CERAMIC,DISC;2.2nF,20%,50V,Y5T,TP,5.0x”
PC28 2201-000338 “C-CERAMIC,DISC;2.2nF,20%,50V,Y5T,TP,5.0x”
PC57 2201-000532 “C-CERAMIC,DISC;4.7nF,10%,50V,Y5P,TP,8x3.”
PC55 2201-000532 “C-CERAMIC,DISC;4.7nF,10%,50V,Y5P,TP,8x3.”
PC52 2201-000532 “C-CERAMIC,DISC;4.7nF,10%,50V,Y5P,TP,8x3.”
PC51 2201-000532 “C-CERAMIC,DISC;4.7nF,10%,50V,Y5P,TP,8x3.”
PC62 2201-000565 “C-CERAMIC,DISC;47nF,+80% -20% 50V Y5V 12”
PC61 2201-000565 “C-CERAMIC,DISC;47nF,+80% -20% 50V Y5V 12”
PC60 2201-000565 “C-CERAMIC,DISC;47nF,+80% -20% 50V Y5V 12”
PC59 2201-000565 “C-CERAMIC,DISC;47nF,+80% -20% 50V Y5V 12”
PC27 2201-000674 “C-CERAMIC,DISC;0.82nF,10%,50V,Y5P,BK,5x3”
PC26 2201-000674 “C-CERAMIC,DISC;0.82nF,10%,50V,Y5P,BK,5x3”
Q 2201-000783 “C-CERAMIC,DISC;100nF,+80-20%,50V,Y5V,TP,”
PC15 2201-000806 “C-CERAMIC,DISC;1nF,10%,400V,Y5P,TP,10x5,”
PC11 2201-000806 “C-CERAMIC,DISC;1nF,10%,400V,Y5P,TP,10x5,”
PC35 2201-000838 “C-CERAMIC,DISC;3pF,0.3pF,50V,CH,TP,5x3.5”
PC33 2201-000838 “C-CERAMIC,DISC;3pF,0.3pF,50V,CH,TP,5x3.5”
PC14 2201-000838 “C-CERAMIC,DISC;3pF,0.3pF,50V,CH,TP,5x3.5”
PC10 2201-000838 “C-CERAMIC,DISC;3pF,0.3pF,50V,CH,TP,5x3.5”
JC2 2202-000796 “C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3”
JC1 2202-000796 “C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3”
PC38 2202-000806 “C-CERAMIC,MLC-AXIAL;220pF,10%,50V,Y5P,TP”
PC34 2202-000806 “C-CERAMIC,MLC-AXIAL;220pF,10%,50V,Y5P,TP”
PC15 2202-000806 “C-CERAMIC,MLC-AXIAL;220pF,10%,50V,Y5P,TP”
PC11 2202-000806 “C-CERAMIC,MLC-AXIAL;220pF,10%,50V,Y5P,TP”
PC5 2301-000375 “C-FILM,PEF;100nF,10%,TP,50V,11x12.5x6.5,”
PC4 2301-000375 “C-FILM,PEF;100nF,10%,TP,50V,11x12.5x6.5,”
PC3 2301-000375 “C-FILM,PEF;100nF,10%,TP,50V,11x12.5x6.5,”
PC2 2301-000375 “C-FILM,PEF;100nF,10%,TP,50V,11x12.5x6.5,”
PC7 2301-000379 “C-FILM,PEF;10nF,10%,50V,TP,6x12x3.5mm,-”
PC16 2301-000379 “C-FILM,PEF;10nF,10%,50V,TP,6x12x3.5mm,-”
PC9 2401-000357 “C-AL;100UF,0.2,50V,GP,8*12,5MM,SSL”
PC50 2401-000357 “C-AL;100UF,0.2,50V,GP,8*12,5MM,SSL”
PC21 2401-000357 “C-AL;100UF,0.2,50V,GP,8*12,5MM,SSL”
PC20 2401-000357 “C-AL;100UF,0.2,50V,GP,8*12,5MM,SSL”
PC19 2401-000475 “C-AL;10uF,20%,50V,GP,TP,5x11mm,5mm”
PC18 2401-000475 “C-AL;10uF,20%,50V,GP,TP,5x11mm,5mm”
PC80 2401-000970 “C-AL;22uF,20%,50V,WT,TP,5x11,5”
PC8 2401-001164 “C-AL;33uF,20%,16V,GP,TP,5x11mm,5mm”
PC17 2401-001164 “C-AL;33uF,20%,16V,GP,TP,5x11mm,5mm”
PC100 2401-001538 “C-AL;47uF,20%,25V,GP,TP,5x11mm,5mm”
PC1 2401-001893 “C-AL;100uF,20%,16V,GP,6*7,5MM,TP”
PC36 2401-001893 “C-AL;100uF,20%,16V,GP,6*7,5MM,TP”
PC37 2401-001893 “C-AL;100uF,20%,16V,GP,6*7,5MM,TP”
PC31 2401-002180 “C-AL;2.2uF,20%,50V,GP,TP,5x11mm,5mm”
PC32 2401-002180 “C-AL;2.2uF,20%,50V,GP,TP,5x11mm,5mm”
PCB AH41-00449A “PCB-PCB AMP;MAX-WB650/VB630/675,-,-,-,1.”
AH97-00900M “ASSY-CA’DECK;-,RCD495/695/ST-68,ASSY CA’”
3809-001188 “CABLE-FLAT;30V,80C,240mm,16P,1.25mm,UL28”
6002-000396 “SCREW-TAPPING;BH,+,2,M2,L5,ZPC(WHT),SWCH”
AH39-00021A “LEAD CONNECTOR ASSY;UL1533#28,300MM,-,-,”
AH39-20002D “LEAD CONNECTOR ASSY;5264,-,3P,300MM,2970”
AH59-00075A “DECK;ADR246AMW,1A/RVS,-,-,DC12V,-,-”
AH81-00101A “A/S-BELT SUB;ADR2400S,34.7,6602-001055,-”
AH81-00102A “A/S-SOLENOID;ADR2400-1,MT75-00049A,-,-,-”
AH81-00141A “A/S-HEAD PB;TC881CB,MT59-00044A,-,-,-,-,”
AH81-00363A “A/S-ASSY MOTOR;ADR246DSW,MT91-15012J,-,-”
AH81-00364A “A/S-BELT MAIN1;ADR246DSW,6602-001056,-,-”
AH81-00365A “A/S-BELT MAIN2;ADR246DSW,6602-001057,-,-”
AH81-00368A “A/S-ASSY RP HEAD;ADR246FTW,MT91-11010T,-”
AH61-00413B “BRACKET-DECK;MAX-B550,SPTE 0.3T,0.3T,-,-”
Location no Code no. Description Specifiation Remarks Location no Code no. Description Specifiation Remarks
Samsung Electronics 3-7
