05 CLEANING AND MAINTAINING
English - 43
REPLACING THE CHARCOAL FILTER
If your oven is vented to the inside, the charcoal filter should be replaced every 6 to 12 months and more
often if necessary. The charcoal filter cannot be cleaned. To order a new charcoal filter, contact the Parts
Department at 1-800-627-4368 or your Samsung dealer.
You can also order online at www.samsungparts.com
1. Unplug the oven or turn off the power at the main power
supply.
2. Open the door.
3. Remove the vent grille mounting screws (2 middle screws).
4. Slide the vent grille to the left, then pull it straight out.
5. Push the hook and remove the old filter.
6. Slide a new charcoal filter into place. The filter should rest at
the angle shown.
7. Replace the vent grille and 2 screws and close the door. Turn
the power back on and set the clock.
The angle
The angle
MC17F808KDT_AA_DE68-04224A_EN.indd 43 2013-07-11 �� 11:05:25
