102
Advanced Settings
White Balance
10p White Balance
Gamma
Motion Lighting
O
0
O
-
The displayed image may differ depending on the model.
White Balance
Adjust the color temperature for a more natural picture.
•
R-Offset / G-Offset / B-Offset: Adjust each color’s (red, green, blue) darkness.
•
R-Gain / G-Gain / B-Gain: Adjust each color’s (red, green, blue) brightness.
•
Reset: Resets the White Balance to its default settings.
10p White Balance
Controls the white balance in 10 point interval by adjusting the red, green, and blue brightness.
•
Off / On
Interval: Select interval to adjust.
Red: Adjust the red level.
Green: Adjust the green level.
Blue: Adjust the blue level.
Reset: Resets the 10p White Balance to its default settings.
―
Available when the Picture Mode is set to Movie and when the external input is set to all input.
―
Some external devices may not support this function.
Gamma
Adjust the primary color intensity.
Motion Lighting
Reduces power consumption by reducing screen brightness when the picture on the screen is in motion.
•
Off / On

Samsung MD40C Specifications

General

Panel life	- h
Color gamut	72 %
Pixel pitch	0.15375 x 0.46125 mm
Touchscreen	-
Response time	8 ms
Display diagonal	40 \
Display brightness	350 cd/m²
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	48 - 75 Hz
Horizontal scan range	30 - 81 kHz
Display number of colors	16.78 million colors
Active display area (W x H)	885.6 x 498.15 mm
Supported graphics resolutions	1920 x 1080 (HD 1080)
Orientation	Horizontal
Product color	Black
Product design	Digital signage flat panel
Panel mounting interface	200 x 200 mm
Internal memory	1 GB
Processor model	A9
Processor family	ARM Cortex
Processor frequency	1 GHz
Computer system type	Thin client
Audio formats supported	AC3
Image formats supported	PNG
Video formats supported	H.264, MPEG1, MPEG2, VC-1
Internal storage capacity	4 GB
Operating system installed	Linux
L2 cache	512 KB
User memory	2.8 GB
Memory clock speed	1333 MHz
Sustainability certificates	ENERGY STAR
RMS rated power	20 W
Number of built-in speakers	2
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (sleep)	0.5 W
Power consumption (standby)	- W
Power consumption (typical)	58 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Package depth	153 mm
Package width	1043 mm
Package height	596 mm
Package weight	12000 g

Weight and Dimensions

Depth	93.5 mm
Width	925.4 mm
Height	542.6 mm
Weight	9800 g
