Samsung MD40C User Manual

17
Removing the Packaging (for MD55C models only)
―
The following images are for reference only. Real-life situations may differ from what is shown in the
images.
1
Remove the black locking device at the bottom of the box.
321
2
Using the grooves in the box, lift and remove the top of the box.
3
Check the components and remove the styrofoam and plastic bag.
―
The appearance of actual components may differ from the image shown.
4
Store the box in a dry area so that it can be used when moving the product in the future.

Samsung MD40C Specifications

General

Panel life	- h
Color gamut	72 %
Pixel pitch	0.15375 x 0.46125 mm
Touchscreen	-
Response time	8 ms
Display diagonal	40 \
Display brightness	350 cd/m²
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	48 - 75 Hz
Horizontal scan range	30 - 81 kHz
Display number of colors	16.78 million colors
Active display area (W x H)	885.6 x 498.15 mm
Supported graphics resolutions	1920 x 1080 (HD 1080)
Orientation	Horizontal
Product color	Black
Product design	Digital signage flat panel
Panel mounting interface	200 x 200 mm
Internal memory	1 GB
Processor model	A9
Processor family	ARM Cortex
Processor frequency	1 GHz
Computer system type	Thin client
Audio formats supported	AC3
Image formats supported	PNG
Video formats supported	H.264, MPEG1, MPEG2, VC-1
Internal storage capacity	4 GB
Operating system installed	Linux
L2 cache	512 KB
User memory	2.8 GB
Memory clock speed	1333 MHz
Sustainability certificates	ENERGY STAR
RMS rated power	20 W
Number of built-in speakers	2
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (sleep)	0.5 W
Power consumption (standby)	- W
Power consumption (typical)	58 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Package depth	153 mm
Package width	1043 mm
Package height	596 mm
Package weight	12000 g

Weight and Dimensions

Depth	93.5 mm
Width	925.4 mm
Height	542.6 mm
Weight	9800 g
