■ OUTDOOR PCB : DB93-02893A(MH068FXEA4/MH080FXEA4/MH30VP2X/MH30VW2X)(cont.)
CN53 3711-000998
CONNECTOR-HEADER
BOX,5P,1R,2.5mm,STRAIGHT,SN,RED 1 SNA
CN54 3711-001000
CONNECTOR-HEADER
BOX,5P,1R,2.5mm,STRAIGHT,SN 1 SNA
CN55 3711-000997
CONNECTOR-HEADER
BOX,5P,1R,2.5mm,STRAIGHT,SN 1 SNA
CN56 3711-000996
CONNECTOR-HEADER
BOX,5P,1R,2.5mm,STRAIGHT,SN 1 SNA
CN57 3711-004182
CONNECTOR-HEADER
BOX,10P,1R,2mm,STRAIGHT,SN,NTR 1 SNA
CN58 3711-000176
CONNECTOR-HEADER
1WALL,2P,1R,3.96mm,STRAIGHT,SN 1 SNA
CN59 3711-004349
CONNECTOR-HEADER
BOX,3P,1R,2mm,STRAIGHT,SN 1 SNA
CN62 3711-000262
CONNECTOR-HEADER
1WALL,3P,1R,7.92mm,STRAIGHT,SN,W 1 SNA
D102,D401,D402,D403 0402-000351 DIODE-RECTIFIER 1N4937,600V,1A,DO-41,TP 4 SNA
D103 0402-001427 DIODE-RECTIFIER ES1D,200V,1A,DO-214AC,TP 1 SNA
D201,D451 0407-000123 DIODE-ARRAY DAN202K,80V,100mA,CA2-3,SOT-23,TP 2 SNA
DSA DB47-00016A POSISTOR DSA-332mA,2pF MAX,100Mohm,ASM-3500 1 SA
FT00 DB27-00023A
COIL CHOKE-LS320038
LS320038,,3.8mH,10%, 1 SNA
FT01 DB27-00024A
COIL CHOKE-LS321026
LS321026,,2.6mH,10% 1 SNA
FUSE 3601-001381 FUSE-Cartrage 250V/30A 1 SNA
IC01 DB09-00238A IC MICOM ML66517,-,80 P,5 V,25 MHz,OTP,-,24,16,QF 1 SNA
IC11 1203-003527
IC-PWM CONTROLLER
TOP243,DIP,7P,9.83x6.6mm,PLASTIC 1 SNA
IC12,IC61,IC62 0604-001172 PHOTO-COUPLER TR,100-300,200mW,SOP,TP 3 SNA
IC13 1203-002948 IC-POSI.ADJUST REG TL431ACD,SOP,8P,4.9x3.9mm,PLASTIC 1 SNA
IC16,IC19 DB95-00594A
ASSY-VOLTAGE REGULATOR
KIA78M05,KA78M05 2 SNA
IC20 1006-001210
IC-BUS TRANSCEIVER
485,DIP,8P,300MIL,SINGLE,ST,PL 1 SNA
IC21,IC42 1202-000104 IC-VOLTAGE COMP 393,SOP,8P,150MIL,DUAL,36V,CMO 2 SNA
IC30 0801-000393 IC-CMOS LOGIC 74HC86,OR GATE,SOP,14,150MIL,QUAD,S 1 SNA
IC31 0604-001003 PHOTO-COUPLER TR,50-150%,200mW,DIP-4,ST 1 SNA
IC41 1201-000166 IC-OP AMP
LM358,SOP,ST,8P,150MIL,DUAL,100V/mV,PLASTIC
1 SNA
IC71 1103-001175 IC-EEPROM 93LC56,128x16,SOP,8P,5x4mm,2.5/6.0V,-40 1 SNA
IC72 0506-000175 TR-ARRAY 2003,NPN,7,1W,SOP-16,ST,1000 1 SNA
IC73,IC59 1203-003334 IC-RESET S-801,SOT-23,5P,2.9x1.6mm,PLASTIC,3.716 2 SNA
IC81 DB95-00595A
ASSY-PHOTO COUPLER
ASSY-PHOTO COUPLER 1 SNA
LED1 0601-001373 LED ROUND,RED,3mm,630nm 1 SNA
LED2 0601-001375 LED ROUND,GRN,3mm,570nm 1 SNA
LED3 0601-000402 LED ROUND,YEL,3x4.0mm,585nm,- 1 SNA
PT02 DB26-00049A TRANS PULSE PT_50,,10,65.5,8~14,EI2218, 1 SNA
Q801 0504-000127 TR-DIGITAL KSR1102,NPN,200mW,10K/10K,SOT-23,TP 1 SNA
Q901,Q902,Q903,Q904 0504-000001 TR-DIGITAL
DTA114EKA,PNP,200mW,10K/10K,SOT-23,TP
4 SNA
R001 2006-001080 R-CEMENT(S) 200ohm,5%,5W,CB,BK,13x9x25.5mm 1 SNA
R101 2003-000855 R-METAL OXIDE(S) 47Kohm,5%,3W,AA,TP,6x16mm 1 SNA
R102 2007-001074 R-CHIP 6.8ohm,5%,1/8W,TP,2012 1 SNA
R103,R512,R601,R604 2007-000468 R-CHIP 1Kohm,5%,1/8W,TP,2012 4 SNA
R104 2007-000686 R-CHIP 3.3Kohm,5%,1/8W,TP,2012 1 SNA
R105 2007-001222 R-CHIP 9.09Kohm,1%,1/8W,TP,2012 1 SNA
Location No. Code No. Description Q'TY SA/SNA RemarkSpecification
24296A(1)_1 11/11/05 5:04 PM Page 4-86
