Electrical Parts List
6-30Samsung Electronics
■ OUTDOOR PCB : DB93-02893A(MH068FXEA4/MH080FXEA4/MH30VP2X/MH30VW2X)(cont.)
R106,R203,R204 2007-000263 R-CHIP 1.82Kohm,1%,1/8W,TP,2012 3 SNA
R107 2003-000708 R-OXIDE 47ohm,5%,1W,MOR1W47ohmJTB 1 SNA
R112,R113,R114 2007-000924 R-CHIP 470Kohm,1%,1/4W,TP,3216 3 SNA
R115 2007-000385 R-CHIP 14.3Kohm,1%,1/4W,TP,3216 1 SNA
R202 R207 2007-002667 R-CHIP 90.9Kohm,1%,1/4W,TP,3216 2 SNA
R205,R208 2007-000671 R-CHIP 2Kohm,5%,1/8W,TP,2012 2 SNA
R301 2007-000023 R-CHIP 120ohm,5%,1/8W,TP,2012 1 SNA
R302,R304,R305,R315,R513,R514, 2007-000300 R-CHIP 10Kohm,5%,1/8W,TP,2012 20 SNA
R515,R516,R706,R708,R709,R710,
R711,R712,R716,R717,R720,R725,
R726,R805
R307,R308,R309,R310, 2007-000944 R-CHIP 47Kohm,5%,1/4W,TP,3216 8 SNA
R311,R312,R313,R314
R401,R402,R403,R404, 2007-000290 R-CHIP 100ohm,5%,1/8W,TP,2012 8 SNA
R405,R406,R425,R426
R407 2007-000872 R-CHIP 4.7Kohm,5%,1/8W,TP,2012 1 SNA
R408,R409,R410 2007-000781 R-CHIP 33ohm,5%,1/8W,TP,2012 3 SNA
R412,R427,R718,R719 2007-000465 R-CHIP 1Kohm,1%,1/8W,TP,2012 4 SNA
R413,R414,R415,R429,R430,R431 2007-008261 R-CHIP 150Kohm,1%,1/2W,TP,5025 6 SNA
R417 2007-008562 R-CHIP 30.1ohm,1%,1/8W,TP,2012 1 SNA
R418,R419,R432 2007-009114 R-CHIP 110Kohm,1%,1/2W,TP,5025 3 SNA
R420 2007-000515 R-CHIP 2.7Kohm,1%,1/8W,TP,2012 1 SNA
R421 2006-001130 R-CEMENT 7mohm,5%,15W,WR15P,ABCO 1 SNA
R422 2007-000938 R-CHIP 47Kohm,1%,1/8W,TP,2012 1 SNA
R423,R509,R707 2007-000546 R-CHIP 20Kohm,5%,1/8W,TP,2012 3 SNA
R424 2007-000868 R-CHIP 4.7Kohm,1%,1/8W,TP,2012 1 SNA
R501,R504 2007-002903 R-CHIP 18.2K-F,1/12W,1608 2 SNA
R502,R503,R724 2007-000613 R-CHIP 24Kohm,1%,1/8W,TP,2012 3 SNA
R505,R506,R507,R508,R723 2007-000763 R-CHIP 330ohm,1%,1/10W,TP,1608 5 SNA
R510,R704 2007-000477 R-CHIP 1Mohm,5%,1/8W,TP,2012 2 SNA
R511,R911,R912,R913 2007-000964 R-CHIP 5.1Kohm,5%,1/8W,TP,2012 4 SNA
R602,R603 2007-000766 R-CHIP 330ohm,5%,1/8W,TP,2012 2 SNA
R701,R702,R703 2007-000282 R-CHIP 100Kohm,5%,1/8W,TP,2012 3 SNA
R705 2007-000976 R-CHIP 5.62Kohm,1%,TP,2012 1 SNA
R713,R714,R715 2007-000511 R-CHIP MCR10EZH,J242,2.4Kohm,1/8W,5%,2012 3 SNA
R721,R722 2007-000297 R-CHIP 10Kohm,1%,1/8W,TP,2012 2 SNA
R722 2007-000297 R-CHIP 10Kohm,1%,1/8W,TP,2012 1 SNA
R806,R807 2007-000553 R-CHIP 20ohm,5%,1/4W,TP,3216 2 SNA
R808 2007-000931 R-CHIP 470ohm,5%,1/8W,TP,2012 1 SNA
R901,R902,R903,R904, 2007-001318 R-CHIP 1Kohm,5%,1/4W,DA,TP,3216 7 SNA
R905,906,R907
R908,R909,R910 2007-001175 R-CHIP 8.2Kohm,1%,1/10W,TP,1608 3 SNA
Location No. Code No. Description Q'TY SA/SNA RemarkSpecification
