Samsung ML-2251N/XAA - Top Cover

5-5
Samsung Electronics
Disassembly and Reassembly
Service Manual
1. Before you remove the Top Cover Ass’y, you
should remove:
- Front Cover
- Rear Cover
2. Remove four screws securing the Top Cover
Ass’y, as shown below.
Exit Roller
5.5 Top Cover
Take Care.
When removing or refitting the top cover take care not to damage the Exit Roller.
