6-13
Samsung Electronics
ALIGNMENT & ADJUSTMENTS
Service
Manual
COMPONENT REPLACEMENT CYCLE
Transfer Roller 60,000 Pages
Fuser 80,000 Pages
Toner Cartridge 5,000 Pages cartridge supplied with set
5,000 Pages replacement cartridge
6.5 Consumables and Replacement Parts
The life cycle outlined below is a general guideline for maintenance purposes and is for reference only.
Environmental conditions (temperature, humidity, dust etc.) and actual use can cause these figures to vary.
6.6 The LED Status Display by Each Error
ERROR LED Status DCU CODE
Open Fuser Error The [Error] LED (red) and the [Toner Save] LED are simultaneously 60
flashing at 1 second intervals.
Over Heat Error The [Error] LED (orange) and the [Toner Save] LED are 68
simultaneously flashing at 1 second intervals.
Low Heat Error The [Error] LED (red) and the [Toner Save] LED are simultaneously 62
flashing at 4 second intervals.
LSU not Ready Error The [Error] LED (green) and the [Toner Save] LED are 95
(Pmotor Error) simultaneously at 1 second intervals.
LSU Not Ready Error The printing is stop in the fad status, and the [Error] LED (green) and 96
(HSYNC Error)
the [Toner Save] LED are simultaneously flashing at 4 second intervals.
