7-17
Samsung Electronics
Troubleshooting
Service Manual
7.3.10 Printed Vertical Lines become curved
• Description
When printing, vertical lines are not straight.
Check and Cause Solution
Use EDC diagnostic code 05 to test the LSU motor.
1. Check stability of 24V supply to LSU.
1. 24V stable - Replace LSU. 24V unstable replace
SMPS, if the problem persists replace the main
PBA.
To Next Page
