Samsung ML-3471ND User Manual

4.2.3 The cause and solution of the bad discharge 4-40
4.2.4 The cause and solution of the malfunction
4-49
4.2.5 Toner Cartridge Service
4-59
4.2.6 The cause and solutions of bad environment of the software 4-64
5. Exploded Views & Parts List
5.1 Main 5-2
5.2 Cover Ass'y
5-4
5.3 Front Cover Ass'y
5-6
5.4 Rear Cover Ass'y
5-8
5.5 OPE Cover Ass'y
5-9
5.6 Frame
5-10
5.7 MP Ass'y
5-14
5.8 Main Drive Ass'y
5-16
5.9 Fuser Drive Ass'y
5-18
5.10 Duplex Unit (Optional)
5-19
5.11 Fuser Unit
5-21
5.12 Cassette Unit
5-23
6. System Diagram
6.1 Block Diagram 6-1
6.1 Connection Dia ram
6-2
7. Reference Information
7.1 Troubleshooting Tools 7-1
7.2 Acronyms and Abbreviations
7-2
7.3 Selecting printer locations
7-4
Continued

Samsung ML-3471ND Specifications

General

Color	No
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Internal memory	64 MB
Processor model	Samsung
Built-in processor	Yes
Maximum internal memory	320 MB
Sound power level (standby)	26 dB
Sound pressure level (printing)	52 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Envelopes sizes	9, 10, DL
Maximum print size	216 x 297 mm
Paper tray media types	Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Custom media sizes	(76 x 127 mm) - (216 x 356 mm)
Networking features	Ethernet 10/100Base-TX
Compatible operating systems	Windows 2000/XP/2003/Vista Mac OS 8.6-9.2 Mac OS 10.1-10.4 Linux OS (Red Hat 8-9, Fedora Core 1-4, Mandrake 9.2-10.1, SuSE 8.2-9.2)

Weight and Dimensions

Dimensions (WxDxH)	400 x 433.4 x 285 mm
