Installation
Wired Remote Controller Installation
Optional accessories
Item
Wired Remote
Controller
Cable Tie Cable Clamp M4X16 Screw User Manual
Installation
Manual
U Terminal
Quantity 1235116
Shape
CAUTION
• The Wired Remote Controller should be installed by an installation expert.
• Check and confirm the power is off before installing your Wired Remote Controller.
• Install the Wired Remote Controller cables in accordance with the electrical wiring rules, and allow it to pass through
the inner area of the wall so that other people can’t reach it.
External Dimensions
120.0(4.72)
124.0(4.88)
63.8(2.51)
19.5(0.76)
[Unit : mm(inch)]
To Next Page
