4-6 Samsung Electronics
Troubleshooting
4-2-2 AMP Pre-Inspection relating to Power Protection
If you think, there are problems at the AMP PART, you can check the PCB without disassemble the set.
(Caution!!: Do not connect the power cord during bellow check!)
Measurement Resistance using Tester
- Approximately -
F/R CH 2kΩ
SUBWOOFER 2kΩ
<Table 4-2>
If Measured Resistance is very different from above numbers. There is a Problem. → AMP PART Problem
2CH SPEAKER OUT
GND
RIGHT
LEFT
To Next Page
