Samsung MX-C730 - Electrical Part List

Samsung Electronics 5-4
Exploded View & Part List
This Document can not be used without Samsung’s authorization.
5-3 Electrical Part List
Loc. No. Part No. Description Specification Qty. SNA Remark
P001A AH44-00222C DC VSS-HP MX-C630,ORTP-560C,AC/DC,120W,A 1 SA
M0014 AH96-00424A ASSY PCB P-MAIN MX-C730/XAP-XAX 1 SA
AAC1 2203-005249 C-CER,CHIP 100nF,10%,50V,X7R,TP,1608 22 SA
AAC14 2203-000888 C-CER,CHIP 4.7nF,10%,50V,X7R,TP,1608 1 SA
AAL2 AH27-00067A COIL FILTER MAX-DA75,22.4uH,50m Ohm,19.0 2 SNA
AAR11 2007-000312 R-CHIP 10ohm,5%,1/4W,TP,3216 4 SA
AAR39 2007-000123 R-CHIP 1.5Kohm,5%,1/10W,TP,1608 4 SA
AC124 2203-000998 C-CER,CHIP 0.047nF,5%,50V,C0G,1608 2 SNA
AC139 2203-000491 C-CER,CHIP 2.2nF,10%,50V,X7R,1608 6 SA
AC28 2203-001607 C-CER,CHIP 0.22nF,5%,50V,NP0,1608 1 SA
AC510 3708-001577 CONNECTOR-FPC/FFC/PIC 30P,1.25mm,STRAIGH 1 SA
AD1 0407-000116 DIODE-SWITCHING KDS181,DAP202K,SDS2836,8 1 SNA
AD480 2203-001386 C-CER,CHIP 100nF,10%,100V,X7R,TP,3216,3. 18 SNA
AD480 2203-006333 C-CER,CHIP 10000nF,20%,16V,X5R,TP,3216 3 SNA
AD480 2203-006336 C-CER,CHIP 10000nF,10%,25V,X5R,3216 9 SA
AD480 2203-006698 C-CER,CHIP 1000nF,10%,25V,X7R,1608 2 SA
AD480 2203-002494 C-CER,CHIP 470nF,10%,16V,X7R,2012 1 SNA
AD480 2203-006391 C-CER,CHIP 1000nF,10%,10V,X7R,TP,1608 1 SNA
AD480 2203-007513 C-CER,CHIP 10000nF,10%,10V,X5R,TP,1608 7 SA
AHR40 2007-000088 R-CHIP 7.5Kohm,5%,1/10W,TP,1608 4 SNA
AQ7 0504-000128 TR-DIGITAL FJV3103R,NPN,200mW,22K/22Kohm 3 SA
AQ8 0504-000156 TR-DIGITAL KSR2103,PNP,200MW,22K/22K,SOT 1 SA
AR02 2007-000125 R-CHIP 3.9Kohm,5%,1/10W,TP,1608 2 SA
AR108 2007-000097 R-CHIP 47Kohm,5%,1/10W,TP,1608 13 SA
AR150 2007-000078 R-CHIP 1Kohm,5%,1/10W,TP,1608 27 SA
AR158 2007-000077 R-CHIP 470ohm,5%,1/10W,TP,1608 1 SA
AR164 2007-000076 R-CHIP 330ohm,5%,1/10W,TP,1608 2 SA
AR174 2007-000129 R-CHIP 27Kohm,5%,1/10W,TP,1608 5 SA
AR28 2007-000683 R-CHIP 3.3Kohm,1%,1/10W,TP,1608 1 SA
AR30 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 18 SA
AR42 2007-000939 R-CHIP 47Kohm,1%,1/10W,TP,1608 2 SA
AR61 2007-000869 R-CHIP 4.7Kohm,1%,1/10W,TP,1608 1 SNA
ARR2 2007-000102 R-CHIP 100Kohm,5%,1/10W,TP,1608 14 SA
AVC08 2203-002398 C-CER,CHIP 22nF,10%,50V,X7R,1608 1 SNA
C 2401-004106 C-AL 680uF,20%,50V,-,BK,12.5 x 35,5 2 SA
C102 2203-006158 C-CER,CHIP 100nF,10%,16V,X7R,1005 23 SA
C1025 2402-000173 C-AL,SMD 4.7uF,20%,35V,GP,TP,4.3x4.3x5.4 2 SA
C125 2203-006361 C-CER,CHIP 10000nF,10%,10V,X5R,TP,2012 19 SC
C134 2203-000257 C-CER,CHIP 10nF,10%,50V,X7R,TP,1608 7 SA
C212 2203-000440 C-CER,CHIP 1nF,10%,50V,X7R,TP,1608 15 SA
C23 2203-006890 C-CER,CHIP 10000nF,20%,6.3V,X5R,1608 26 SNA
C258 2203-000236 C-CER,CHIP 0.1nF,5%,50V,C0G,1608 16 SA
C272 2203-005627 C-CER,CHIP 470nF,10%,10V,X5R,1608 3 SNA
C3 2203-000384 C-CER,CHIP 0.015nF,5%,50V,C0G,1608 5 SNA
C3502 2203-001222 C-CER,CHIP 0.82nF,10%,50V,X7R,1608 2 SNA
C637 2203-001656 C-CER,CHIP 0.47nF,5%,50V,NP0,1608 6 SA
