5-5 Samsung Electronics
Exploded View & Part List
This Document can not be used without Samsung’s authorization.
Loc. No. Part No. Description Specification Qty. SNA Remark
C776 3716-001242 TERMINAL-BLOCK WIRE TYPE,4P,4.5mm,0V,0A 1 SA
CA5602 2401-003378 C-AL 1000uF,20%,10.000V,WT,10x12.5,5mm 2 SA
CER02 2007-000071 R-CHIP 22ohm,5%,1/10W,TP,1608 2 SA
CER04 2007-000084 R-CHIP 4.7Kohm,5%,1/10W,TP,1608 13 SA
CIS3 AH40-00157A TUNER TAF-7F02,MAX-DG35,FM,75 ohm,Coaxia 1 SA
CN1 3708-000491 CONNECTOR-FPC/FFC/PIC 23P,1mm,STRAIGHT,S 1 SA
CN1804 3711-003411 HEADER-BOARD TO CABLE BOX,5P,1R,2mm,STRA 1 SA
CN9 3708-001755 CONNECTOR-FPC/FFC/PIC 15P,1mm,STRAIGHT,S 1 SA
D001A AH59-02289A DECK-MECHA ASSY(CKD) BD-E1,MX-C630 / MX- 1 SC
D1 0401-001099 DIODE-SWITCHING 1N4148WS,75V,150mA,SOD-3 9 SA
DR01A 0402-001427 DIODE-RECTIFIER ES1D,200V,1A,DO-214AC,TP 2 SA
DR1 2007-000023 R-CHIP 120ohm,5%,1/8W,TP,2012 1 SA
DR10 2007-000113 R-CHIP 33ohm,5%,1/10W,TP,1608 20 SA
DR32 3301-000314 BEAD-SMD 120ohm,1.6x0.8x0.8mm,-,-,- 2 SNA
DS01A 0401-001166 DIODE-SWITCHING BAV20WS-V,150V,250mA,SOD 2 SA
DU501 1203-001824 IC-VOL. DETECTOR 7042,SOT-89,3P,PLASTIC, 1 SA
ER19 2007-002899 R-CHIP 10ohm,1%,1/10W,TP,1608 9 SA
FAR22 2007-000082 R-CHIP 3.3Kohm,5%,1/10W,TP,1608 13 SA
HE4 2203-006474 C-CER,CHIP 22000nF,20%,6.3V,X5R,2012 3 SA
HRP2 2011-001344 R-NETWORK 100ohm,5%,1/16W,L,CHIP,8P,TP,2 12 SA
IC012 1203-006057 IC-POSI.ADJUST REG. KIA1085FP00,D2PAK,3P 1 SA
IC112 1103-001410 IC-EEPROM S-24CS08AFJ-TB-1GE,8Kbit,1Kx8, 2 SNA
IC520 0903-001565 IC-MICROCONTROLLER LC87F5NC8AVU,QFP,100P 1 SNA
IDR23 2007-000116 R-CHIP 120ohm,5%,1/10W,TP,1608 2 SNA
J914 2007-000029 R-CHIP 0ohm,5%,1/8W,TP,2012 1 SC
JC10 2203-006324 C-CER,CHIP 2200nF,10%,10V,X5R,1608 3 SA
JC31 2203-000715 C-CER,CHIP 3.3nF,10%,50V,X7R,1608 4 SNA
KAC5 2203-001126 C-CER,CHIP 0.68nF,10%,50V,X7R,1608 3 SNA
KAR11 2007-000124 R-CHIP 2.2Kohm,5%,1/10W,TP,1608 8 SNA
KAR13 2007-000060 R-CHIP 100Kohm,1%,1/10W,TP,1608 4 SNA
KAR21 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 4 SA
KAR7 2007-000120 R-CHIP 680ohm,5%,1/10W,TP,1608 5 SA
KAR9 2007-000093 R-CHIP 20Kohm,5%,1/10W,TP,1608 2 SA
KCON2 3708-001439 CONNECTOR-FPC/FFC/PIC 4P,1mm,STRAIGHT,SN 1 SA
KOP1 1201-000163 IC-OP AMP 4560,SOP,8P,173MIL,DUAL,100V/m 3 SA
KQ6 0501-000341 TR-SMALL SIGNAL KSC1623-L,NPN,200mW,SOT- 5 SA
KR7 2007-000402 R-CHIP 150ohm,5%,1/10W,TP,1608 1 SA
M0081 6003-001375 SCREW-TAPTYPE BH,+,-,B,M3,L8,ZPC(WHT),SW 2 SA
MC68 2402-001096 C-AL,SMD 220UF,20%,16V,GP,TP,6.6X6.6X7.7 3 SA
MD1 0404-001089 DIODE-SCHOTTKY RB551V-30,20V,500MA,SOD-3 2 SA
MIC1 1003-001978 IC-MOTOR DRIVER AM5766,HSOP28H,28P,17.9x 1 SA
MIC2 1105-001573 IC-DRAM K4S281632,-,128Mbit,8Mx16Bit,TSO 1 SA
MPD8 0402-000156 DIODE-RECTIFIER 1N5402,200V,3A,DO-201AD 3 SA
MPIC1 AH14-10003E IC KIA7812PI,,TO-220 1 SA
MR103 2007-000308 R-CHIP 10ohm,5%,1/8W,TP,2012 4 SA
MR112 2007-000309 R-CHIP 10ohm,5%,1/10W,TP,1608 6 SA
MR122 2007-000094 R-CHIP 22Kohm,5%,1/10W,TP,1608 8 SA
MR16 2007-000098 R-CHIP 56Kohm,5%,1/10W,TP,1608 3 SA
MR166 2007-000119 R-CHIP 560ohm,5%,1/10W,TP,1608 1 SA
