Samsung Electronics 5-6
Exploded View & Part List
This Document can not be used without Samsung’s authorization.
Loc. No. Part No. Description Specification Qty. SNA Remark
MR19 2007-000087 R-CHIP 6.8Kohm,5%,1/10W,TP,1608 5 SA
MR2 2007-000130 R-CHIP 39Kohm,5%,1/10W,TP,1608 4 SA
MR312 2007-000450 R-CHIP 180ohm,5%,1/10W,TP,1608 1 SNA
MR34 2007-000118 R-CHIP 390ohm,5%,1/10W,TP,1608 4 SA
MR9 2007-000455 R-CHIP 18Kohm,1%,1/10W,TP,1608 4 SA
MROP1 2007-000090 R-CHIP 10Kohm,5%,1/10W,TP,1608 27 SA
MX1 2801-004284 CRYSTAL-SMD 27MHz,10ppm,28-AAN,20pF,30oh 1 SA
P803T 1404-001483 THERMISTOR-PTC 470ohm,50%,32V,TP 2 SA
PC69 2203-006818 C-CER,CHIP 47000nF,20%,6.3V,X5R,3216 2 SA
PCN1 3710-001990 CONNECTOR-SOCKET 15P,2R,1.25mm,STRAIGHT, 2 SA
PIC2 1203-002185 IC-POSI.FIXED REG. 3RD13,TO-220,4P,402MI 1 SA
PPC2 2203-005148 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 58 SA
PPD1 0402-000309 DIODE-RECTIFIER 1SR154-400,400V,1A,SOD-1 2 SA
PR4 2007-000052 R-CHIP 10Kohm,1%,1/10W,TP,1608 14 SA
PR6 2007-000072 R-CHIP 47ohm,5%,1/10W,TP,1608 9 SNA
Q1040 0501-000457 TR-SMALL SIGNAL MMBT2222A/KST2222A,NPN,3 1 SA
Q4 0501-000632 TR-SMALL SIGNAL 2SB1197K,PNP,200mW,SOT-2 2 SA
R1 2007-002425 R-CHIP 1ohm,5%,1/10W,TP,1608 8 SNA
R104 2007-000148 R-CHIP 10Kohm,5%,1/16W,TP,1005 1 SA
R105 2007-000138 R-CHIP 100ohm,5%,1/16W,TP,1005 2 SA
R15 2007-000134 R-CHIP 33Kohm,5%,1/10W,TP,1608 1 SNA
R1P151 2007-000121 R-CHIP 820ohm,5%,1/10W,TP,1608 5 SA
R1S36 2007-000491 R-CHIP 2.2Kohm,1%,1/10W,TP,1608 2 SA
R320 2007-000458 R-CHIP 18Kohm,5%,1/10W,TP,1608 1 SA
R329 2007-000081 R-CHIP 2.7Kohm,5%,1/10W,TP,1608 4 SA
R331 2007-000079 R-CHIP 1.8Kohm,5%,1/10W,TP,1608 12 SA
R419 2007-000882 R-CHIP 4.7ohm,5%,1/10W,TP,1608 2 SA
R505 2007-000496 R-CHIP 2.2Kohm,5%,1/4W,TP,3216 2 SA
R512 2007-000107 R-CHIP 470Kohm,5%,1/10W,TP,1608 1 SA
R807 2007-001134 R-CHIP 68ohm,5%,1/10W,TP,1608 1 SA
R809 2007-000475 R-CHIP 1Mohm,1%,1/10W,TP,1608 1 SA
R830 2007-000101 R-CHIP 82Kohm,5%,1/10W,TP,1608 2 SA
R893B 2007-000122 R-CHIP 1.2Kohm,5%,1/10W,TP,1608 3 SA
RC11 2203-005015 C-CER,CHIP 150nF,+80-20%,16V,Y5V,1608 1 SA
RC34 2203-000280 C-CER,CHIP 0.01nF,0.5pF,50V,C0G,1608 5 SA
RIC1 1201-001842 IC-OP AMP TL3472CD,SO,TP,8P,-,DUAL,-,PAL 1 SA
RIC3 1003-001508 IC-MOTOR DRIVER FAN8082DTF,SOP,8P,200MIL 2 SA
RR2 2007-000075 R-CHIP 220ohm,5%,1/10W,TP,1608 4 SA
S1H0220 2402-000120 C-AL,SMD 10UF,20%,50V,GP,TP,6.6X6.6X5.4M 1 SA
T0087 1203-000293 IC-POSI.FIXED REG. 7808,TO-220,3P,PLASTI 1 SA
T0527 AA68-01544A LABEL-LINE ALL MDL COMMON 1 SNA
T0568 3301-001404 BEAD-SMD 30ohm,2012,TP,15.9OHM/30MHz 14 SA
U1502 1203-001212 IC-VOL. DETECTOR 7029,SOT-89,3P,-,PLASTI 1 SA
UR16 2007-000552 R-CHIP 20ohm,5%,1/10W,TP,1608 4 SA
UR28 2007-001026 R-CHIP 560Kohm,5%,1/10W,TP,1608 1 SA
UR53 2007-000305 R-CHIP 10Mohm,5%,1/10W,TP,1608 1 SA
UX2 2802-001174 RESONATOR-CERAMIC 10MHZ,0.5%,BK,8X3.5X3M 1 SA
VC4 2203-000357 C-CER,CHIP 0.15nF,5%,50V,C0G,1608 8 SA
