5-7 Samsung Electronics
Exploded View & Part List
This Document can not be used without Samsung’s authorization.
Loc. No. Part No. Description Specification Qty. SNA Remark
WC31 2305-000407 C-FILM,LEAD-PEF 470nF,5%,100V,TP,10.5x6x 2 SA
X202 2801-004371 CRYSTAL-SMD 12.288MHz,50ppm,SX-1,18pF,50 1 SNA
XT01 0201-001578 ADHESIVE-HM HM-555,WHT,4,000 Cps 0.5 SNA
X-TAL1 2801-001394 CRYSTAL-UNIT .032768MHz,20ppm,28-AAY,12. 1 SNA
ZC14 2203-000626 C-CER,CHIP 0.022nF,5%,50V,C0G,1608 4 SNA
ZC35 2203-000681 C-CER,CHIP 0.027nF,5%,50V,C0G,1608 2 SA
ZIC3 1107-001709 IC-FLASH MEMORY MX25L1605DM2I-12G,16Mbit 1 SNA
ZPR3 2007-000106 R-CHIP 220Kohm,5%,1/10W,TP,1608 1 SA
ZR10 2007-001164 R-CHIP 75ohm,1%,1/10W,TP,1608 4 SA
ZR24 2007-000109 R-CHIP 1Mohm,5%,1/10W,TP,1608 3 SA
ZR45 2007-000329 R-CHIP 11Kohm,5%,1/10W,TP,1608 1 SA
ZRN10 2011-001261 R-NETWORK 33ohm,5%,1/16W,L,CHIP,8P,TP,2. 7 SA
ZVL3 3301-001495 BEAD-SMD 120ohm,2012,2500mA,TP,115ohm/10 2 SA
ZVR8 2007-000824 R-CHIP 390ohm,5%,1/4W,TP,3216 9 SA
0202-001463 SOLDER-WIRE LFC2-W3.0,-,D3,99.79Sn/0.2Cu 4.215 SNA
0202-001477 SOLDER-CREAM LST309-M,D20~45um,96.5Sn/3A 1.57 SNA
0202-001608 SOLDER-WIRE FLUX LFC7-107,D0.8,99.3Sn/0. 0.025 SNA
0204-002420 SOLVENT 1M-1000,C3H70H,96 4.83 SNA
0204-002607 FLUX DF-234U,13%,14KG,Gravity 0.82 5.616 SNA
0205-001154 OIL-SILICON G746 0.4 SNA
0205-001154 OIL-SILICON G746 0.2 SNA
0403-001164 DIODE-ZENER MMSZ5232B,5.32-5.88V,500MW,S 2 SA
0406-001128 DIODE-TVS MLVS-0603-E08,50V 1 SA
0501-000150 TR-SMALL SIGNAL 2SA1037,PNP,200mW,SOT-23 1 SA
0505-002582 FET-SILICON IRFI4019HG-117P,N,150,8.7,0. 2 SA
1003-002268 IC-GATE DRIVER IRS2053MTRPBF,MLPQ,48P,7X 1 SA
1204-002968 IC-MODULATOR PS9830B,TQFP,100P,14x14mm,P 1 SA
1204-003124 IC-PAL/NTSC DECODER ES8396SCD,LQFP,216P, 1 SA
2007-000253 R-CHIP 1.5ohm,5%,1/4W,TP,3216 2 SA
2007-000504 R-CHIP 2.2ohm,5%,1/4W,TP,3216 2 SA
2007-007065 R-CHIP 10ohm,5%,1W,TP,6432 5 SA
2007-007625 R-CHIP 0ohm,5%,1W,TP,6432 4 SA
2011-001345 R-NETWORK 10Kohm,5%,1/16W,L,CHIP,8P,TP,2 1 SA
2301-001760 C-FILM,MPEF 100nF,10%,250V,TP,B5xH13.5x1 2 SA
AH41-01287B PCB MAIN MX-C750,FR-4,2,T1.6,197*235,PCB 1 SNA
AH62-00227A HEAT SINK-MAIN2 MAX-DC630,AL,10,45,80,MA 1 SNA
AH62-00231A HEAT SINK-ASSY MAX-DC630,al,2,32,83,wht, 1 SNA
AH95-00015A ASSY SUB PCB-HEAT SINK MX-C730 1 SNA
AH97-04821A ASSY AUTO MAIN PCB ASSY,MX-C730/SMT,CD,M 1 SNA
AH97-05134A ASSY SMD MX-C730/XAP,CD,MIC,FM ONLY,2,AH 1 SNA
AH97-05313B ASSY MICOM-MICOM IC HMC730WWM-1005.0,201 1 SNA
AH97-05313F ASSY MICOM-NOR FLASH HMC-C730WWB-1005.0, 1 SNA
AH91-00178A ASSY SPEAKER MX-C730/XAO-XAP 1 SNA
SP01A AH96-00217D ASSY SPEAKER P 4 OHM,2.0CH,PS-C730 SPK S 1 SNA
ASP02 AH81-05679A SPEAKER-SYSTEM PS-C630,SPEAKER SYSTEM 2 SA
F001 AH64-05255A PANEL FRONT PS-C630,ABS 4 SNA
AH64-05256A DECORATION PS-C530,ABS 4 SNA
