Samsung MX-C730 - Page 35

Samsung Electronics 5-2
Exploded View & Part List
This Document can not be used without Samsung’s authorization.
 Part List
Loc. No. Part No. Description;Specification Qty. SNA Remark
AC060 AH64-05213A CABINET-SIDE-L;MAX-DC630,HIPS,10,260,288 1 SA
AC070 AH64-05216A CABINET-SIDE-R;MAX-DC630,HIPS,10,260,288 1 SA
AC274 AH63-02051A COVER-MIC;MAX-DC630,ABS+TPU,3,15,30,BLK, 1 SA
AK111 AH64-05215A KNOB-DISC;MAX-DC630,ABS,20,41,250,BLK,MA 1 SA
AK400 AH64-05223A KNOB-TUNER;MAX-DC630,ABS,40,62,81,BLK,MA 1 SA
C0104 3809-001221 CABLE-FLAT;30V,80C,210mm,30P,1.25mm,UL28 1 SA
D001A AH59-02289A DECK-MECHA ASSY(CKD);BD-E1,MX-C630 / MX- 1 SC
ES04 AH61-03018A SPRING ETC-DOOR;MX-DC630,SUS304,0.6,4.4, 1 SA
F001A AH96-00234H ASSY COVER P-FRONT;MAX-DC630,ASSY,BLK,MA 1 SA
FD17 AH64-05217A DOOR-CD;MAX-DC630,ABS,2.5,30,61,165,BLK 1 SA
FK01 AH64-05224B KNOB-VOLUME;MAX-DC630,ABS,60,60,60,BLK,M 1 SA
FK08 AH64-05221B KNOB POWER;MAX-DC630,ABS+PMMA,40,62,81,B 1 SA
M0014 AH96-00424A ASSY PCB P-MAIN;MX-C730/XAP-XAX; AH94-02 1 SA
MF01 AH82-00211B A/S ASSY-FORNT VFD;MX-C730,ALL BUYER 1 SA
MF02 AH82-00211A A/S ASSY-FRONT KEY PCB;MX-C730,ALL BUYER 1 SA
P001A AH44-00222C DC VSS-HP;MX-C630,ORTP-560C,AC/DC,120W,A 1 SA
T001 AH64-05214A CABINET-TOP;MAX-DC630,HIPS,36,261,230,BL 1 SA
T0268 AC39-10200A CBF-POWER CORD;AT,EP2/N,HOUING(2P),250V, 1 SA
W390 6003-000276 SCREW-TAPTYPE;BH,+,-,B,M3,L10,ZPC(WHT),S 10 SA
W391 6003-000275 SCREW-TAPTYPE;BH,+,B,M3,L10,ZPC(BLK),SWR 17 SA
