Samsung Electronics 5-10
Exploded View & Part List
This Document can not be used without Samsung’s authorization.
Loc. No. Part No. Description Specification Qty. SNA Remark
1003-002194 IC-VFD PT6324-QL,QFP,52P,14.0x14.0mm,-40 1 SA
AH41-01286A PCB-FRONT MAX-DC630,KB,1,T1.6,168*247,PC 1 SNA
AH68-50254B LABEL-SERIAL T0.1,L10,W42,SME/SEHZ 1 SNA
AH97-04244B ASSY AUTO MAX-DC630/BASIC,1,,AH94-02412B 1 SNA
AH97-04246A ASSY MANUAL INSERT FRONT PCB ASSY,AH94-0 1 SNA
AH92-03354F ASSY P/MATERIAL MX-C730,XAZ 1 SNA
S.N.A 0203-001100 TAPE-OPP MASKING OPP/W75/CLR,T0.075,W75, 2.1 SNA
PE-BAG 6902-000068 BAG PE HDPE/NITRON/HDPE,T0.02/0.5/0.02,W 1 SNA
AH69-02888A CUSHION-LEFT MM-C730,25,512,363,90 1 SNA
BH69-00418A BAG WRAPPING LDPE,762,1828M,SAMEX FACTOR 6.27 SNA
T0527 BN68-00129A LABEL SHIPPING-00 LABEL SHIPPING,ART-PAP 1 SNA
BN69-03565F PAD-PLATE 22LB450,CB,SW,YEL,W1250,D1050, 1 SNA
BN69-05528A PACKING INNER PAD COMM,CB,3,1828.8,100,C 1 SNA
AH91-00220A ASSY SHIELD MX-C730/XAO,XAP 1 SNA
P025 AC39-10200A CBF-POWER CORD AT,EP2/N,HOUING(2P),250V, 1 SA
AH68-50282E LABEL CAUTION MM-N2/N4/N7,MAM,VINYL,-,-, 1 SNA
