ENG
21
RADIO
FM
Signal/noise ratio 55 dB
Usable sensitivity 12 dB
Total harmonic distortion 0.5 %
AM (Optional)
Signal/noise ratio 35 dB
Usable sensitivity 70 dB
Total harmonic distortion 4 %
COMPACT DISC PLAYER
Capacity 1 disc
Frequency range 20 Hz - 20 KHz (± 2 dB)
Signal/noise ratio 70dB (at 1kHz, with filter, 2V)
Distortion 0.1 % (at 1 KHz)
Channel separation 70 dB
Disc sizes Diameter: 120 or 80 mm. Thickness: 1.2 mm
AMPLIFIER
Output power
MX-D730-
200 Watts (10% THD)
Front Speaker 100W/CH (6 Ω/100Hz)
MX-D730-
240 Watts (MAX. THD)
Front Speaker 120W/CH (6 Ω/100Hz)
MX-D750-
400 Watts (10% THD)
Front Speaker 120W/CH (6 Ω/100Hz)
Subwoofer 160W/CH (4 Ω/100Hz)
MX-D750-
460 Watts (MAX. THD)
Front Speaker 140W/CH (6 Ω/100Hz)
Subwoofer 180W/CH (4 Ω/100Hz)
Channel separation 60 dB
Signal/noise ratio 70 dB
GENERAL
Dimensions 230 (W) x 317 (H) x 313 (D) mm
Weight 3.5 Kg
SAMSUNG strives to improve its products at all times. Both the design specifications and these user instructions are
thus subject to change without notice.
Technical Specifications
*: Nominal specification
- Samsung Electronics Co., Ltd reserves the right to change the specifications without notice.
- Weight and dimensions are approximate.
- Design and specifications are subject to change without prior notice.
- For information on the power supply and power consumption, refer to the label attached to the product.
