Samsung NV70K3370BS User Manual

English 11
Operations
Control panel
The front panel comes in a wide range of materials and colours. For improved
quality, the actual appearance of the oven is subject to change without notice.
01 0902 0504 06 07 0803
01 Mode selector Turn to select a cooking mode or function.
02 Temperature Use to set the temperature.
03 Cooking time Press to set the cooking time.
04 Timer Timer helps you check the time or operating duration while
cooking.
05 OK Press to conrm your settings.
06 Back Cancel current settings, and return to the main screen.
07 Oven light
(
Child lock)
Press to turn the internal light on or off.
The oven light turns on automatically when the oven operation
starts. And it turns off automatically after a certain period of
inactivity in order to save power.
Child lock : To prevent accidents, Child lock disables all
controls. But you can switch off by turning the mode selector
to off. Hold down for 3 seconds to activate, or hold down for
3 seconds again to deactivate the lock on the control panel.
08 Display Shows necessary information of selected modes or settings.
09 Value dial Use the value dial to:
• Set the cooking time or temperature.
• Choose a sub item of top-level menus: Cleaning, Auto cook,
Special function, or Grill.
• Choose a serving size for Auto Cook programmes.
Common settings
It is common to change the default temperature and/or cooking time across all
cooking modes. Follow the steps below to adjust the temperature and/or cooking
time for the selected cooking mode.
Temperature
1. Turn the mode selector to choose a mode
or function. The default temperature of
each selection appears.
2. Turn the value dial to set a desired
temperature.
3. Press OK to conrm your changes.
NOTE
If you do not make any further settings within a few seconds, the oven starts
cooking automatically with the default settings.
To change the set temperature, press
button and follow the above steps.
Operations
NV70K3370BS_SA_DG68-00751E-00_EN.indd 11 2017-10-12  9:50:07

Samsung NV70K3370BS Specifications

General

Oven size	Medium
Oven type	Electric
Cleaning type	Pyrolytic + Steam
Number of ovens	1
Total oven power	- W
Microwave cooking	-
Convection cooking	Yes
Oven thermostat range	30 - 250 °C
Auto programs quantity	20
Total oven(s) interior capacity	70 L
AC input voltage	230 V
AC input frequency	50 Hz
Energy efficiency index (EEI)	94
Energy consumption (conventional)	0.99 kWh
Energy consumption (forced convection)	0.79 kWh
Door hinge	down
Control type	Rotary
Display type	LED
Product color	Black, Stainless steel
Control position	Front
Interior material	Enameled ceramic
Appliance placement	Built-in
Number of glass door panels	3
Clock type	Electronic
Timer type	Digital
Package depth	646 mm
Package width	682 mm
Package height	656 mm
Package weight	41000 g

Weight and Dimensions

Depth	566 mm
Width	595 mm
Weight	38800 g
Installation compartment depth	545 mm
Installation compartment width	560 mm
Installation compartment height	572 mm
Interior dimensions (W x D x H)	560 x 545 x 572 mm
