Samsung NV70K3370BS User Manual

English 17
Operations
4. Use a dry cloth to clean inside the oven.
WARNING
Do not open the door before the cycle is complete. The water inside the oven is
very hot, and it can cause a burn.
NOTE
• If the oven is heavily soiled with grease, for example, after roasting or grilling,
it is recommended to remove stubborn soils manually using a cleaning agent
before activating Steam cleaning.
• Leave the oven door ajar when the cycle is complete. This is to allow the interior
enamel surface to dry thoroughly.
• While the oven is hot inside, auto cleaning is not activated. Wait until the oven
cools down, and try again.
• Do not pour water onto the bottom by force. Do it gently. Otherwise, the water
overows to the front.
Pyro cleaning
Pyrolytic features high temperature thermal cleaning. It burns off oily leftovers to
facilitate manual cleaning.
1. Remove all accessories including the side
runners, and wipe out large pieces of
impurities manually from inside the oven.
Otherwise, they may cause ames during
the cleaning cycle, resulting in re.
2. Turn the mode selector to select .
Cleaning
Two cleaning modes are available for you. This function saves you time by
removing the need for regular manual cleaning. The remaining time appears on
the display during this process.
Function Instructions
C 1 Steam cleaning This is useful for cleaning light soiling with steaming.
C 2 Pyro cleaning
Pyrolytic features high temperature thermal cleaning.
It burns off oily leftovers to facilitate manual cleaning.
Steam cleaning
This is useful for cleaning light soiling with steaming.
1. Pour 400 ml (3/4 pint) of water onto the
bottom of the oven and close the oven
door.
2. Turn the mode selector to select .
3. Turn the value dial to select C 1 (Steam
cleaning), and then press OK to start
cleaning.
Steam cleaning runs for 26 minutes.
NV70K3370BS_SA_DG68-00751E-00_EN.indd 17 2017-10-12  9:50:09

Samsung NV70K3370BS Specifications

General

Oven size	Medium
Oven type	Electric
Cleaning type	Pyrolytic + Steam
Number of ovens	1
Total oven power	- W
Microwave cooking	-
Convection cooking	Yes
Oven thermostat range	30 - 250 °C
Auto programs quantity	20
Total oven(s) interior capacity	70 L
AC input voltage	230 V
AC input frequency	50 Hz
Energy efficiency index (EEI)	94
Energy consumption (conventional)	0.99 kWh
Energy consumption (forced convection)	0.79 kWh
Door hinge	down
Control type	Rotary
Display type	LED
Product color	Black, Stainless steel
Control position	Front
Interior material	Enameled ceramic
Appliance placement	Built-in
Number of glass door panels	3
Clock type	Electronic
Timer type	Digital
Package depth	646 mm
Package width	682 mm
Package height	656 mm
Package weight	41000 g

Weight and Dimensions

Depth	566 mm
Width	595 mm
Weight	38800 g
Installation compartment depth	545 mm
Installation compartment width	560 mm
Installation compartment height	572 mm
Interior dimensions (W x D x H)	560 x 545 x 572 mm
