Samsung NV75N7677RS User Manual

English 7
Installation
Installation
WARNING
This oven must be installed by a qualied technician. The installer is responsible
for connecting the oven to the main power, while observing the relevant safety
regulations of your area.
What’s included
Make sure all parts and accessories are included in the product package. If you
have a problem with the oven or accessories, contact a local Samsung customer
centre or the retailer.
Oven at a glance
01
02
04
03
01 Control panel 02 Door handle 03 Up door
04 Main door
Accessories
The oven comes with different accessories that help you prepare different types of
food.
Wire rack Wire rack insert * Baking tray *
Universal tray * Extra-deep tray * Rotisserie spit *
Rotisserie spit and
Shashlik *
Telescopic rail * Divider
Meat probe * 2 screws (M4 L25) Install Handle
NOTE
Availability of accessories with an asterisk (*) depends on the oven model.
NV75N7677RS_EU_DG68-01054C-00_EN+DE.indb 7 2018-02-12  3:45:00

Samsung NV75N7677RS Specifications

General

AC input voltage	230 V
AC input frequency	50 Hz
Energy consumption (conventional)	1.05 kWh
Energy consumption (forced convection)	0.71 kWh
Grill	Yes
Oven size	Medium
Oven type	Electric
Cleaning type	Pyrolytic
Steam cooking	No
Number of ovens	1
Convection power	1200 W
Total oven power	- W
Keep warm function	-
Oven thermostat range	40 - 250 °C
Auto programs quantity	50
Total oven(s) interior capacity	75 L
Maximum temperature (convection)	275 °C
Door hinge	down
Control type	Rotary, Touch
Display type	LED
Product color	Black, Stainless steel
Control position	Front
Housing material	Stainless steel
Appliance placement	Built-in
Number of glass door panels	2
Timer type	Digital
Lamp type	Halogen
Package depth	660 mm
Package width	694 mm
Package weight	53700 g

Weight and Dimensions

Depth	570 mm
Width	595 mm
Weight	49000 g
Installation compartment depth	549 mm
Installation compartment width	560 mm
Installation compartment height	572 mm
