Samsung NX2000 User Manual

124
Wireless network
Connecting to a WLAN and conguring network settings
Learn to connect via an access point (AP) when you are in a range of a
WLAN. You can also congure network settings.
Connecting to a WLAN
1
On the Mode screen, touch Wi-Fi → Auto Backup, Email,
SNS & Cloud, or Samsung Link.
2
Touch → Wi-Fi Setting.
• In some modes, follow the on-screen instructions until the Wi-Fi
Setting screen appears.
• The camera automatically searches for available AP devices.
3
Touch an AP.
Refresh
Samsung1
Samsung2
Samsung3
Samsung4
• Touch Refresh to refresh connectable APs.
• Touch Add wireless network to add an AP manually. Your AP name
must be in English to add the AP manually.
Icon Description
Ad hoc AP
Secured AP
WPS AP
Signal strength
Open network setting options.
• When you select a secured AP, a pop-up window appears. Enter the
required passwords to connect to the WLAN. For information about
entering text, refer to "Entering text". (p. 127)
• When a login page appears, refer to "Using the login browser".
(p. 125)
• When you select an unsecured AP, the camera will connect to the
WLAN.
• If you select a WPS prole supported AP, touch → WPS PIN
connection, and then enter a PIN on the AP device. You can also
connect to a WPS prole supported AP by touching
→ WPS
button connection on the camera, and then pushing the WPS
button on the AP device.

Samsung NX2000 Specifications

General

Megapixel	20.3 MP
Camera type	MILC
Sensor type	CMOS
Sensor format	Advanced Photo System type-C (APS-C)
Image stabilizer	Yes
Total megapixels	21.6 MP
Image sensor size	- \
Image formats supported	JPG, MPO, RAW
Supported aspect ratios	1:1, 3:2, 16:9
Maximum image resolution	- pixels
Still image resolution(s)	480 x 480, 640 x 424, 1280 x 1280, 1920 x 1080, 1920 x 1280, 2000 x 2000, 3008 x 1688, 3008 x 2000
Digital zoom	2 x
Optical zoom	- x
Focal length range	50 - 200 mm
Lens mount interface	Samsung NX
Minimum aperture number	-
Minimum focal length (35mm film equiv)	- mm
Auto Focus (AF) points	21
Auto focusing (AF) modes	Continuous Auto Focus, Multi Point Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600, Auto
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure correction	± 3EV (1/3EV step)
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Fill-in, Flash off, Red-eye reduction
Flash sync-speed	0.0055 s
Video resolutions	320 x 240, 640 x 480, 1280 x 720, 1920 x 1080 pixels
Video formats supported	H.264, MP4
Maximum video resolution	1920 x 1080 pixels
Audio formats supported	AAC
Memory slots	1
Internal memory	2048 MB
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Field of view	100 %
Display diagonal	3.7 \
Display resolution	800 x 400 pixels
Display resolution (numeric)	1152000 pixels
USB version	2.0
HDMI connector type	Micro
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modes	Fireworks, Night, Panorama, Sunset, Landscape (scenery)
Image editing	Resizing, Rotating
Photo effects	Vivid
White balance	Auto, Cloudy, Custom modes, Daylight, Flash, Fluorescent, Lamp, Tungsten
Camera playback	Movie, Single image, Slide show, Thumbnails
Image processor	DRIMe IV
Self-timer delay	2, 30 s
Languages support	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HEB, HUN, ITA, KOR, LAV, LIT, NOR, POL, POR, RUS, SER, SWE, THA, TUR
Camera file system	DCF, DPOF 1.1, Exif 2.21, RAW
Minimum RAM	512 MB
Minimum processor	Intel Core 2 Duo 2.0 GHz / AMD Phenom 2.4 GHz
Power source type	Battery
Minimum storage drive space	250 MB
Battery type	BP1130
Battery capacity	1130 mAh
Battery life (max)	2.83 h
Battery life (CIPA standard)	340 shots
Product color	White
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 85 %
Cables included	USB
Bundled software	Adobe Photoshop Lightroom 4\\r iLauncher

Weight and Dimensions

Depth	35.7 mm
Width	119 mm
Height	64.5 mm
