Samsung PM32F

26
Chapter 2. Device setup
Setting auto adjustment (Set Auto Adjustment)
Header Command ID Data
length
Data Checksum
0xAA 0x3D 1 “Auto
Adjustment”
“Auto Adjustment” : 0x00 (at all times)
Ack
Header Command ID Data
length
Ack/
Nak
r-CMD Val1 Checksum
0xAA 0xFF 3 'A' 0x3D “Auto
Adjustment”
Nak
Header Command ID Data
length
Ack/
Nak
r-CMD Val1 Checksum
0xAA 0xFF 3 'N' 0x3D "ERR"
“ERR” : A code showing what error has occurred.
Video Wall Mode Control
Function
• Video Wall mode can be activated on a product using a PC.
• This control is only available on a product whose Video Wall is enabled.
Viewing video wall mode (Get Video Wall Mode)
Header Command ID Data length Checksum
0xAA 0x5C 0
Setting the video wall (Set Video Wall Mode)
Header Command ID Data
length
Data Checksum
0xAA 0x5C 1 “Video Wall
Mode”
“Video Wall Mode”: A code used to activate Video Wall mode on a product
• 1: Full
• 0: Natural
Ack
Header Command ID Data
length
Ack/
Nak
r-CMD Val1 Checksum
0xAA 0xFF 3 'A' 0x5C “Video Wall
Mode”
“Video Wall Mode”: A code used to activate Video Wall mode on a product
Nak
Header Command ID Data
length
Ack/
Nak
r-CMD Val1 Checksum
0xAA 0xFF 3 'N' 0x5C "ERR"
“ERR” : A code showing what error has occurred.
