Samsung PM32F

18
Chapter 2. Device setup
WARNING
• Do not fasten the screws too rmly. This may damage the product or cause the
product to fall, leading to personal injury. Samsung is not liable for these kinds
of accidents.
• Samsung is not liable for product damage or personal injury when a non-VESA
or non-specied wall mount is used or the consumer fails to follow the product
installation instructions.
CAUTION
• Always have two people mount the product on a wall.
• Do not use screws that are longer than the standard length or do not comply
with the VESA standard screw specications. Screws that are too long may cause
damage to the inside of the product.
• Do not install your Wall Mount Kit while your product is turned on. It may result
in personal injury due to electric shock.
External connection
Checkpoints
• Before connecting a source device, read the user manual provided with it.
The number and locations of ports on source devices may differ from device to
device.
• Connect the sound ports correctly: left = white and right = red.
• Check the types of ports at the back of the product you want to connect.
The appearance may differ depending on the product.
WARNING
Do not connect the power cable until all connections are completed.
Connecting the power cable during connection may damage the product.
Cable Connection
RS232C Cable
Interface RS232C (9 pins)
Pin TxD (No.2), RxD (No.3), GND (No.5)
Bit rate 9600 bps
Data bits 8 bit
Parity None
Stop bit 1 bit
Flow control None
Maximum length 50 ft (only shielded type)
