Samsung PM32F

62
Chapter 5. Menu
Automatic Network Settings (Wired)
Connect to the network using a LAN cable.
Make sure a LAN cable is connected rst.
How to set up automatically
1 Press the
MENU
button on the remote control.
2 Select Network - Open Network Settings.
3 Select Wired.
‒ Thenetworktestscreenappearsandthenthevericationprocessstarts.
4 When the connection has been veried, select OK.
• If the connection process fails, check the LAN port connection.
• Iftheautomaticprocesscannotndthenetworkconnectionvaluesorifyouwantto
set the connection manually, go to the next section, network setup.
Manual Network Settings (Wired)
Ofces may use static IP addresses.
If this is the case, ask the network administrator for the IP address, subnet mask,
gateway and DNS server address. Enter these values manually.
Getting the Network Connection Values
To view the Network connection values on most Windows computers, follow these
steps.
1 Right click the Network icon on the bottom right of the screen.
2 In the pop-up menu that appears, click Status.
3 On the dialog that appears, click the Support tab.
4 On the Support Tab, click the Details button. The Network connection values are
displayed.
How to set up manually
1 Press the
MENU
button on the remote control.
2 Select Network - Open Network Settings.
3 Select Wired.
‒ Thenetworktestscreenappearsandthenthevericationprocessstarts.
4 Select Stop. The verication process stops.
5 Select IP Settings. The IP Settings screen appears.
6 Select IP Setting and set it to Enter manually.
‒ Setting IP Setting to Enter manually automatically changes DNS Setting to Enter
manually.
7 Enter the network connection values.
‒ IP Address, Subnet Mask, Gateway, DNS Server.
8 When done, select OK at the bottom of the page, and then press
. The network
test screen appears and the verication process starts.
9 When the connection has been veried, select OK.
