4.Troubleshooting

►ErrorCode

H1-1353

►Errormessage

TrayFailure:#H1-1353.Pulltray3outandinsertit.Callforserviceiftheproblempersists

►Symptom

Thepaperisnotfedfromtray3.

►Troubleshootingmethod

1)CheckiftheGear-IdleLiftisbroken.

2)Checkifthecassettedetectionsensorcableisconnectedcorrectly.Unplugandreconnectit.

3)IftheconnectionisOK,replacethecassettedetectionsensor.

4)CheckiftheLift-Motorconnectorisconnectedproperly.

5)Iftheproblempersists,replacetheLift-Motor.
