4.Troubleshooting

►ErrorCode

M1–5112

M1–5113

►Errormessage

Paperislowintray1.Loadpaper

Paperisemptyintray1.Loadpaper.

►Symptom

PaperisemptyinTray1.

►Troubleshootingmethod

1)Checkifthepaperisloadedintray1.Loadthepaper.

2)CheckiftheemptyactuatorofthepickupAssyisassembledcorrectly.Ifitisbrokenordeformed,replaceit.

3)Iftheemptysensorharnessisconnectedcorrectly.Iftheharnessisdefective,replaceit.

4)Iftheemptysensorisdefective,replaceit.

►ErrorCode

M1–5120

►Errormessage

Paperisemptyinalltray.Loadpaper

►Symptom

Paperisemptyinalltray.

►Troubleshootingmethod

1)Checkifthepaperisloadedintray1andMPtray.Loadthepaper.

2)Checkiftheemptyactuatorisassembledcorrectly.Ifitisbrokenordeformed,replaceit.

3)Iftheemptysensorharnessisconnectedcorrectly.Iftheharnessisdefective,replaceit.

4)Iftheemptysensorisdefective,replaceit.
