Supported Resolutions for UHD Input Signals
Check the supported resolution for UHD input signals.
• Resolution: 3840 x 2160p, 4096 x 2160p
This function may not be supported depending on the model.
If Input Signal Plus is set to Off
Frame rate (fps)
Colour Depth /
Chroma
Sampling
RGB 4:4:4 YCbCr 4:4:4 YCbCr 4:2:2 YCbCr 4:2:0
50 / 60 8 bit - - - O
If Input Signal Plus is set to On
• All models for Q6*A/AU/BEA Series and for less than 55-inch models (QLED TV except for 50QN9*A model/The
Frame):
Frame rate (fps)
Colour Depth /
Chroma
Sampling
RGB 4:4:4 YCbCr 4:4:4 YCbCr 4:2:2 YCbCr 4:2:0
50 / 60
8 bit O O O O
10 bit - - O O
• 50QN9*A model
• Supported for 55-inch or larger models of the QLED TV (except for Q6*A Series) and The Frame
Frame rate (fps)
Colour Depth /
Chroma
Sampling
RGB 4:4:4 YCbCr 4:4:4 YCbCr 4:2:2 YCbCr 4:2:0
50 / 60
8 bit O O O O
10 bit *O *O O O
120
8 bit *O *O *O *O
10 bit *O *O *O *O
*: These specications are supported for the HDMI 4 port.
- 161 -
