Table of contents
Before Using the Product
Safety Precautions 4
Safety symbols 4
Electricity and Safety 5
Installation 6
Operation 8
Precautions when handling the panel 10
Cleaning 11
Storage and Maintenance 12
Preparations
Checking the Components 13
Parts 14
Ports 15
Control menu 16
Remote Control 17
2
Before Installing the Product (Installation
Guide) 19
Tilting Angle and Rotation 19
Ventilation 19
Installing the Wall Mount 20
Preparing before installing Wall-Mount 20
Installing the Wall Mount 20
Wall Mount Kit Specifications (VESA) 21
Connecting and Using
a Source Device
Before Connecting 22
Pre-connection Checkpoints 22
Connecting to a PC 22
Connection Using an HDMI Cable 22
Connection Using an HDMI-DVI Cable 23
Connecting to a Video Device 24
Connection Using an HDMI Cable 24
Connection Using an HDMI-DVI Cable 24
Connecting HDMI to Sound system and
Video device 25
Connecting to an Audio System 25
Connecting the LAN Cable 25
Changing the Input source 26
Source 26
Web Browser 27
Workspace 29
SMARTVIEW+ 29
Screen Mirroring 29
Multiple Display Control
Cable Connection 30
RS232C Cable 30
LAN Cable 31
Connection 33
Control Codes 34
Using MDC 41
MDC Program Installation/Uninstallation 41

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Samsung QB50B and is the answer not in the manual?

Samsung QB50B Specifications

General IconGeneral
Haze rate2 %
Pixel pitch0.285 x 0.285 mm
Response time8 ms
RGB color spaceDCI-P3
Color saturation92 %
Display diagonal50 \
Display brightness350 cd/m²
Display technologyVA
Number of displays1
Vertical scan range48 - 75 Hz
Horizontal scan range30 - 81 kHz
Contrast ratio (typical)4000:1
Display number of colors1 billion colors
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Energy efficiency scaleA to G
Power consumption (sleep)0.5 W
Power consumption (typical)143 W
Internal memory8 GB
Computer system typeSystem on Chip (SoC)
Operating system installedTizen 6.5
USB ports quantity2
HDMI ports quantity3
DVI-I ports quantity0
Package depth152 mm
Package width1269 mm
Package height784 mm
Package weight17600 g
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 80 %
OrientationHorizontal/Vertical
Mounting typeWall
Product colorBlack
Product designDigital signage flat panel
Placement supportedIndoor
Panel mounting interface200 x 200 mm
PurposeUniversal
HDCP version2.2
Operating hours (hours/days)16/7
Harmonized System (HS) code85285210
Weight and Dimensions IconWeight and Dimensions
Depth46.3 mm
Display width1121.4 mm
Display height643.9 mm
Display weight13400 g
