Connection
"
Ensure you connect each of the adapters to the correct RS232C IN or OUT port on the
product.
"
Connecting parts may differ depending on the model.
 Connection 1
RS232C IN RS232C OUT RS232C IN RS232C OUT RS232C IN RS232C OUT RS232C IN RS232C OUT
Monitor 1 Monitor 2 Monitor 3 Monitor 4
PC
 Connection 2
RJ45(LAN IN)RJ45(LAN IN) RJ45 RJ45(LAN IN)
5 4 3 2 1
Monitor 2Monitor 1
PC
Monitor 3
 Connection 3
RS232C OUT RS232C IN RS232C OUT RS232C IN RS232C OUT RS232C IN RS232C OUTRJ45(LAN IN)RJ45
Monitor 1 Monitor 2 Monitor 3 Monitor 4
PC
 Connection 4
"
This option is only available for models that have LAN IN and LAN OUT ports.
LAN OUTLAN IN LAN OUTLAN IN LAN OUTLAN IN LAN OUTLAN INRJ45
Monitor 1 Monitor 2 Monitor 3 Monitor 4
PC

Samsung QE55T Specifications

General

Screen Size	55 inches
Resolution	3840 x 2160 (4K UHD)
HDR Support	HDR10+
Smart TV	Yes
Operating System	Tizen
Refresh Rate	60 Hz
USB Ports	2
Bluetooth	Yes
Wi-Fi	Yes
