61
Input Signal Plus
Expands the input signal range for HDMI connections.
HDMI1 (Off ( ) / On ( ))
"
When Input Signal Plus is set to On, up to the 3840 x 2160 @ 60 Hz resolution is supported.
(Up to 7680 x 4320 @ 60 Hz resolution is supported for the QPR-8K model only, if connected
to HDMI IN 4.)
When Input Signal Plus is set to Off, up to the 3840 x 2160 @ 30 Hz resolution is supported.
"
Connecting parts may differ depending on the model.
"
This function may not be supported depending on the model.
Supported Resolutions for UHD Input Signals
Check the supported resolution for UHD input signals.
Resolution: 3840 x 2160p, 4096 x 2160p
If Input Signal Plus is set to Off
Frame rate
(fps)
Colour Depth /
Chroma Sampling
50 / 60 8 bit - - - O
If Input Signal Plus is set to On
Frame rate
(fps)
Colour Depth /
Chroma Sampling
50 / 60
8 bit O O O O
10 bit - - O O
12 bit - - O O
Resolutions for Input Signals supported by QPR-8K model series
Check the resolutions for input signals supported by QPR-8K model series.
If Input Signal Plus is set to On
Resolution: 3840 x 2160p
Frame rate
(fps)
Colour Depth /
Chroma Sampling
50 / 60
8 bit O O O O
10 bit *O *O O O
12 bit - - O O
120 10 bit *O *O *O *O
"
*: These specifications are supported for the HDMI 4 port.
Resolution: 7680 x 4320
Frame rate
(fps)
Colour Depth /
Chroma Sampling
24 / 30 8 bit / 10 bit *O *O *O *O
50 / 60 8 bit / 10 bit - - - *O
"
*: These specifications are supported for the HDMI 4 port. Use an HDMI cable that supports
these specifications
Motion Lighting
Reduces power consumption by reducing screen brightness when the picture on the screen is
in motion.
Off / On
"
This feature is not available for videowall displays.
