18
3-2) Refrigerator Door
DISASSEMBLY AND REASSEMBLY
Refrigerator
Door
Part Name How To Do Descriptive Picture
1. After removing the screw,
disassemble the Upper Right
Hinge Cover with opening door.
2. Disconnect electric wire on the
top of the refrigerator.
3. With the 7/16 inch wrench,
remove the three bolts that
holds the hinge on the top of
the refrigerator.
4. Remove the screw that hold the
ground wire.
5. Separate Hinge from electric
wire and ground wire as shown
in the picture.
To Next Page
