26
DISASSEMBLY AND REASSEMBLY
3-11) Door Handle Freezer
Door Handle
Freezer
Part Name How To Do Descriptive Picture
1. Remove the Cap Door with a
flat-blade(-) screwdriver.
2. Lift the handle up with force in
the direction of arrow.
3-12) Freezer Light
Freezer Light
Part Name How To Do Descriptive Picture
1. Remove the lamp cover by
pushing the hook of lamp cover.
2. Remove the LED panel by lifting
the left part of LED panel while
pushing it to right. (Refer to
pictrue)
